Tool and Die Steel D2 Bars

George Metals Located in Houston, USA, offers to manufacture and supply high quality metal products such as Tool and Die Steel with specialties in Tool and Die Steel D2 Bars which stands out for high hardness, abrasion resistance and dimension stability. They can be suitable to be applied on tooling parts, mainly used in making of dies and punches, to give precision accuracy where durability is one of the necessary requirements of use. George Metals has made sure that D2 bars are in many sizes and suited to various industries’ specific requirements, bringing with them outstanding reliability and quality for their customers.

AISI D2 Tool Steel Round Bars Dealer in California, Tool Steel T30402 Bar Manufacturer in Houston, Chrome Moly Steel D2 Round Bars Supplier in West Houston, D2 Tool and Alloy Steel Bars Price List in USA, Die Steel D2 Bars Supplier in Texas, ASTM A681 D2 Tool Steel Round Bars Size Chart, Tool and Die Steel T30402 Threaded Bar Price List in Texas, Alloy Steel D2 Rods Stockist in Houston, Die Steel Round Bar D2 Supplier in Texas

D2 Tool Steel Round Bar

Die Steel D2 Rods

D2 Tool and Die Steel Bar

What is Tool and Die Steel D2 Bars?

D2 tool and die steel bar is a high-carbon, high-chromium steel known for its excellent resistance to wear, hardness, and toughness. It generally contains about 1.50% carbon, 12.00% chromium, 0.90% molybdenum, and 0.80% vanadium along with trace amounts of manganese, silicon, and phosphorus. Upon heat treatment, D2 steel reaches a hardness of around 58-62 HRC, which makes it very suitable for applications with high wear-resistance requirements, e.g., punches and dies and shear blades. Some other mechanical properties include high tensile strength, good machinability, and resistant to abrasive wear albeit at greater risk of fracturing owing to the brittleness.

Tool Steel 1.2379 Round Bars Exporter in Texas, Alloy Steel D2 Round Bars Stockist in Houston, D2 Die Steel Alloy Steel Bars Supplier in Houston, IS-T90MN6WCR2 Cold Drawn Bar Distributor in Houston, D2 Hot Rolled Alloy Steel Bar Stockist USA, High Quality D2 Cold Work Die Steel Round Bar Price in California, High-carbon Steel D2 Round Bars And Rods Price List, Tool Steel UNS T30402 Rods Supplier in Texas, Quenched & Tempered D2 Alloy Steel Bar Manufacturer in California

Tool and Die Steel D2 Bars Specifications

Standard : ASTM A681, ASME SA681
Dimensions : EN, DIN, JIS, ASTM, BS, ASME, AISI
Form : Round
Diameter : 10 mm ~ 900 mm
Size : 0.08 mm to 25.00 mm
Diameter Range : 0.040 mm – 12 mm (0.0016” – 0.4724”)
Application : Lathe Tools, Milling Cutter, Cutter Blades, Boring Tools, Twist drills, Milling Knives, Reamers, Taps, Metalcutting saws, Screw Cutting Tools, File Cutter’s Chissels, Drills, Hobs, Drill Bits, Tread cutting tools etc

Chemical Compositions of Tool and Die Steel D2 Bars

ASTM A681	C		Mn		P	S	Si		Cr		V		Mo
D2	1.4	1.6	0.1	0.6	0.03	0.03	0.1	0.6	11	13	0.5	1.1	0.7	1.2
DIN ISO 4957	C		Mn		P	S	Si		Cr		V		Mo
1.2379/X153CrMo12	1.45	1.6	0.2	0.6	0.03	0.03	0.15	1.6	11	13	0.7	1	0.7	1
JIS G4404	C		Mn		P	S	Si		Cr		V		Mo
SKD11	1.4	1.6		0.6	0.03	0.03		0.4	11	13	0.2	0.5	0.8	1.2

Mechanical Properties of Tool and Die Steel D2 Bars

Mechanical Properties	Metric	Imperial
Hardness, Knoop (converted from Rockwell C hardness)	769	769
Hardness, Rockwell C	62	62
Hardness, Vickers	748	748
Izod impact unnotched	77.0 J	56.8 ft-lb
Poisson’s ratio	0.27-0.30	0.27-0.30
Elastic modulus	190-210 GPa	27557-30457 ksi

You Need Our Support, to Have Any Projects?

Test Certificate

Why George Metals?

Packaging

Equivalent Grades of Tool and Die Steel D2 Bars

Country	USA	German	Japan
Standard	ASTM A681	DIN EN ISO 4957	JIS G4404
Grades	D2	1.2379/X153CrMo12	SKD11

Thermal Properties of Tool and Die Steel D2 Bars

Properties		Conditions
Properties		T (°C)	Treatment
Thermal expansion	10.4 x 10^-6/ºC	20-100	–

Modern Equipments

Expert Engineers

Well Maintained

Efficient Factories

Tool and Die Steel D2 Bars Types

ASME SA681 Tool Steel D2 Hot Forged Bars Exporter in West Houston, Stockist of D2 Die Steel Bars in Houston, UNS T30402 Round Bars Supplier in USA, Skd11 Round Bar Price List in Houston,High-chromium D2 Bars Exporter in West Houston , Tool and Die Steel D2 Bars Exporter in USA, Alloy Steel D2 Rods Supplier in Houston, CrMo D2 Cold Drawn Round Bars Manufacturer in West Houston , D2 Tool Steel Alloy Steel Round Bars Distributor in USA, Carbon Steel D2 Hot Rolled Round Bars Dealer in California

Frequently Asked Questions (FAQ)

Can Tool and Die Steel D2 Bars Be Welded?

Tool and Die Steel D2 Bars can be welded, but it's challenging due to their high carbon content. Preheating, post-weld heat treatment, and using specific filler materials are essential.

Is Tool And Die Steel D2 Bars Corrosion-resistant?

Tool and Die Steel D2 Bars are semi-corrosion-resistant due to high chromium content (12%). While not fully stainless, they offer moderate resistance to rust in less aggressive environments.

How Should Tool and Die Steel D2 Bars Be Stored?

Tool and Die Steel D2 Bars should be stored in a dry, ventilated area to prevent moisture exposure. Use protective coatings like oil or rust inhibitors to minimize corrosion risk.

Tool and Die Steel D2 Bars Uses

D2 tool and die steel bars are extensively used in the manufacturing industries, where high wear resistance and durability are necessary. Typical applications include cutting tools, dies, molds, punches, shear blades, and stamping tools. Because of its high hardness and resistance to abrasion, it is used as a forming and shaping agent for metals, plastics, and other materials. D2 is also employed in cold working tools such as blanking dies, threading tools, and deep drawing die presses, where high precision and durability are required. While D2 is still popular among manufacturers in automotive, aerospace, and metalworking industries for tools that are subject to high wear, it is rather brittle when subjected to impact.
