George Metals, a leading manufacturer and supplier located in Houston, USA, specializes in high-quality Stainless Steel 310S Flat Bars that are engineered for outstanding performance in high-temperature and oxidizing environments. The 310S variant is a low-carbon form of Stainless Steel 310, which not only enhances weldability but also maintains excellent resistance to heat and corrosion. These flat bars are crafted in line with ASTM A276 and other international standards, guaranteeing precise dimensional tolerances and a smooth surface finish. George Metals caters to a diverse array of industries, including heat treatment, power generation, petrochemical, and furnace construction, providing flat bars that consistently perform well under extreme conditions
Stainless Steel 310S Flat Bars are made up of roughly 24–26% Chromium, 19–22% Nickel, and a low carbon content (maximum 0.08%) to improve weldability. This austenitic stainless steel boasts exceptional oxidation resistance at temperatures reaching up to 1100°C and has a tensile strength ranging from 520–750 MPa. It retains its structural integrity even at elevated temperatures and shows good creep resistance. George Metals guarantees reliable mechanical performance, corrosion resistance, and precise dimensions in every batch, making these flat bars ideal for thermal processing and challenging industrial applications
| Specifications | ASTM A 276 / SA 276 |
|---|---|
| Dimensions | ASTM, ASME |
| Range | 3.17 MM TO 350 MM DIA |
| Diameter | 25mm to 152m |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Finish | Bright, Polish & Black |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wiremesh, Billet, Ingot, Forging Etc., |
| Condition | Cold Drawn & Polished Cold Drawn, Centreless Ground & Polished |
| Cr | Ni | C | Si | Mn | P | S | Mo | Cu | Fe |
|---|---|---|---|---|---|---|---|---|---|
| 24.0-26.0 | 19.2-22.0 | .25 Max | 1.50 Max | 2.00 Max | .045 Max | .03 Max | .75 Max | .50 Max | Balance |
| Temperature, °F | Ultimate Tensile Strength, ksi | .2% Yield Strength, ksi | Elongation Percent |
|---|---|---|---|
| 70 | 80.0 | 35.0 | 52 |
| 1000 | 67.8 | 20.8 | 47 |
| 1200 | 54.1 | 20.7 | 43 |
| 1400 | 35.1 | 19.3 | 46 |
| 1600 | 19.1 | 12.2 | 48 |
|
Type |
SIZES (mm) |
SIZES (Inches) |
ISO Tolerance |
|---|---|---|---|
|
Cold Drawn and Polish |
3.00 – 75.00 |
1/8 – 3.00 |
h8-h9-h10-h11 |
|
Cold Drawn and Ground |
10.00 – 75.00 |
5/6 – 2.50 |
h8-h9-h10-h11 |
|
Peeled and Polished |
40.00 – 150.00 |
1.50 – 6.00 |
h11, h11-DIN 1013 |
|
Peeled and Ground |
20.00 – 50.00 |
3/4 – 2.00 |
h9-h10-h11 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310 | 1.4841 / 1.4307 | S31000 | SUS 310 | 310S24 | 20Ch25N20S2 | – | X15CrNi25-20 |
| Diameter | Wght | Dia | Wght |
|---|---|---|---|
| (mm) | per metre (kg) | (in) | per metre (kg) |
| 3 | 0.06 | 1/8″ | 0.06 |
| 4 | 0.10 | 3/16″ | 0.14 |
| 5 | 0.16 | 1/4″ | 0.25 |
| 6 | 0.22 | 5/16″ | 0.39 |
| 7 | 0.30 | 3/8″ | 0.56 |
| 8 | 0.40 | 7/16″ | 0.77 |
| 10 | 0.62 | 1/2″ | 1.00 |
| 12 | 0.89 | 9/16″ | 1.22 |
| 14 | 1.22 | 5/8″ | 1.56 |
| 15 | 1.40 | 11/16″ | 1.89 |
| 16 | 1.59 | 3/4″ | 2.25 |
| 18 | 2.01 | 7/8″ | 3.07 |
| 20 | 2.48 | 1″ | 4.03 |
| 22 | 3.00 | ||
| 24 | 3.57 | ||
| 25 | 3.88 |
Stainless Steel 310S Flat Bars are extensively utilized in scenarios that require high resistance to heat and oxidation. In the heat treatment and furnace sectors, they are perfect for components like burner trays, heat shields, and retorts. In petrochemical and refinery settings, they find use in reformer tubes, radiant sections, and high-temperature piping. Power plants depend on 310S for superheater tubes and exhaust components. Their remarkable thermal stability also makes them suitable for kilns, incinerators, and fluid bed combustors. George Metals offers precision-cut 310S flat bars customized for demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
