To satisfy a variety of industrial demands, George Metals, a reputable manufacturer and supplier with headquarters in Houston, USA, provides premium stainless steel 316L round bars and rods. The marine, chemical processing, and pharmaceutical industries are just a few of the demanding settings where 316L bars and rods are perfect due to their exceptional corrosion resistance and durability. George Metals guarantees that each product meets strict international standards while providing outstanding performance and durability. The company is a preferred source for stainless steel solutions, serving a vast network of clients both domestically and internationally with a strong emphasis on accuracy, dependability, and timely delivery.
The composition of stainless steel 316L round bars and rods is composed of 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and a low carbon content of ≤0.03%, which improves weldability and corrosion resistance. These bars have outstanding elongation and toughness, with a tensile strength of roughly 485 MPa and a yield strength of 170 MPa. In chloride environments, molybdenum increases resistance to pitting and crevice corrosion. 316L is a flexible option for a variety of applications because it also shows good high-temperature strength and retains its mechanical qualities even in cryogenic settings.
| Grade | Stainless Steel 316L (UNS S31603) |
|---|---|
| Specification | ASTM A276/ A479, ASME SA276/SA479 |
| Round bar size | Outside Diameter in the range of 4mm to 500mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | 316 Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Processing | Bar cutting to 650mm |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.3 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16 – 18 | 2 – 3 | 10 – 14 | 0.10 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
|
Type |
SIZES (mm) |
SIZES (Inches) |
ISO Tolerance |
|---|---|---|---|
|
Cold Drawn and Polish |
3.00 – 75.00 |
1/8″ – 3.00″ |
h8-h9-h10-h11 |
|
Cold Drawn and Ground |
10.00 – 75.00 |
5/6″ – 2.50″ |
h8-h9-h10-h11 |
|
Peeled and Polished |
40.00 – 150.00 |
1.50″ – 6.00″ |
h11, h11-DIN 1013 |
|
Peeled and Ground |
20.00 – 50.00 |
3/4″ – 2.00″ |
h9-h10-h11 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐032 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
| Round Bar Grade | Dimensions |
|---|---|
| Stainless Steel Round Bar 316L | 1/2 inch – 12 |
| Flat bar size | 18 meter |
| Square bar size | 1-2 inch |
| Round bar size | 1-2 inch,3-4 inch,2-3 inch |
| Hex Bar size | 0-1 inch,3-4 inch |
Industries that demand exceptional corrosion resistance and structural integrity frequently use stainless steel 316L round bars and rods. They are perfect for shafts, fasteners, and fittings that are exposed to saltwater in the maritime sector. Because they are resistant to corrosive and acidic media, the chemical and pharmaceutical industries use them for pipelines, tanks, and processing equipment. Additionally, they are used in pulp and paper, food processing, and architectural applications. Because of their low carbon content, 316L bars can be welded without worrying about carbide precipitation, guaranteeing durability and functionality in both hot and cold temperatures.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
