George Metals, a Houston, USA-based leading manufacturer and supplier of high-quality metal products, provides diversified solutions with its precision-engineered rectangular bar made of titanium. Reputed for delivering quality, performance, and reliability, George Metals caters to key industries like aerospace, medical, marine, and chemical processing. With high production capacity, rigorous quality control, and conformity to international standards such as ASTM and AMS, the company assures superior material integrity and dimensional accuracy. George Metals is dedicated to delivering exceptional customer service, punctual delivery, and creative metal solutions designed to satisfy the sophisticated needs of today’s engineering applications.
Titanium rectangular bars are generally produced from commercially pure titanium (Grade 2) or from titanium alloys like Grade 5 (Ti-6Al-4V). These grades include titanium with trace amounts of elements like aluminum and vanadium for increased strength. The bars have high strength-to-weight ratio, superior corrosion resistance, and biocompatibility. Mechanical properties include tensile strength ranging from 345 MPa (Grade 2) up to 950 MPa (Grade 5), with elongation between 10–20% and exceptional fatigue resistance. Titanium maintains its mechanical integrity in extreme temperatures, making it ideal for critical load-bearing and corrosion-sensitive applications.
| Standard | ASTM B348/ASME SB348, ASTMF67, ASTM F136, ISO-5832-2(3), AMS4928, MIL-T-9047G, JIS etc |
| Grade | TA1-TA4, TA7-TA10, TA15-TA18, GR1-GR5, GR6,GR7, GR9, GR11, GR12, TI-6AL-4V, TI-6AL-4VELI,GR23 |
| Diameter | 5-350mm |
| Length | Max6000mm |
| Technique | Forging ,Machining |
| Surface | acid surface or polishing, sand blasted surface |
| Shape | Rectangular |
| Application | Metallurgy, electronics, medical, chemical, petroleum, pharmaceutical, aerospace, etc. |
Hardness, Brinell | 120 | 120 | annealed |
Hardness, Knoop | 132 | 132 | Estimated from Brinell. |
Hardness, Rockwell B | 70 | 70 | annealed |
Hardness, Vickers | 122 | 122 | Estimated from Brinell |
Tensile Strength, Ultimate | 240 MPa | 34800 psi | – |
Tensile Strength, Yield | 170 – 310 MPa | 24700 – 45000 psi | – |
Elongation at Break | 24 % | 24 % | – |
Reduction of Area | 35 % | 35 % | – |
Modulus of Elasticity | 105 GPa | 15200 ksi | In Tension |
Compressive Modulus | 110 GPa | 16000 ksi | – |
Poisson’s Ratio | 0.37 | 0.37 | – |
Charpy Impact | 310 J | 229 ft-lb | V-notch |
Shear Modulus | 45 GPa | 6530 ksi | – |
|
Physical Properties |
Metric |
English |
|
Density |
4.51 g/cc |
0.163 lb/in³ |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51 g/cc | 0.163 lb/in³ |
|
STANDARD |
WERKSTOFF NR. |
UNS |
|
Titanium |
3.7035 / 3.7165 / 3.7235 |
R50400 / R56400 / R52400 |
Yes, Titanium Rectangular Bars are machinable, though they require specific tools and techniques due to their strength and hardness compared to other metals.
Yes, Titanium Rectangular Bars are highly resistant to corrosion, particularly in seawater, acids, and other harsh environments, making them ideal for marine and chemical applications.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@georgemetals.us
Titanium rectangular bars find application in a range of high-performance uses owing to their exceptional strength, low weight, and excellent corrosion resistance. They are employed in structural components and engine parts in the aerospace field. Titanium is preferred in medical applications such as implants and surgical instruments on account of their biocompatibility. The marine and offshore sectors employ titanium bars for seawater-exposed shafts, valves, and fittings. They also work in chemical processing facilities for reactors and heat exchangers. Rectangular bars of titanium provide long-term durability and resistance in harsh environments where other metals can fail or deteriorate quickly.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
