George Metals, a reputable manufacturer and supplier of high-quality titanium grade 12 bars and rods with its headquarters located in Houston, USA, serves industries that require remarkable mechanical performance and resistance to corrosion. Our Titanium Grade 12 (Ti-0.3Mo-0.8Ni) products are renowned for their accuracy, dependability, and adherence to global standards. They perform exceptionally well in oxidising and mildly reducing conditions. George Metals provides high-performance titanium solutions for crucial applications where strength, formability, and corrosion resistance are crucial. The company serves clients in the chemical processing, marine, and power generation industries with its sophisticated manufacturing capabilities and unwavering dedication to customer satisfaction.
Titanium Grade 12 Bars/Rods are alpha-phase alloys that contain 0.8% nickel and 0.3% molybdenum. When compared to commercially pure grades, these additions increase strength and corrosion resistance. Grade 12 has an elongation of about 18%, a yield strength of about 345 MPa, and a tensile strength of about 483–550 MPa. In environments containing chloride, it provides exceptional resistance to stress corrosion cracking and crevice corrosion, as well as moderate strength and excellent weldability. Because it retains its formability and durability under a variety of service conditions, it is perfect for demanding industrial applications.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 12 | 3.7105 | R53400 |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 9 | .08 max | .03 max | .25 max | .015 max | Bal | 0.30 max | – | .12 – .25 |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade 12 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Density | Melting Range | Modulus of Elasticity (Tension) | Specific Heat | Mean Coefficient of Expansion | Thermal conductivity | Electrical Resistivity |
| kg/m3 | °C | GPa | J/kg. °C | x10 -6 / °C | W / m. °C | micro-ohm.m |
| 4,507 | 1668± 10 | 103 | 519 | 8.41 | 11.4 | 0.420 |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Grade 12 Titanium Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Titanium Grade 12 offers excellent resistance to corrosion, especially in oxidizing and mildly reducing environments, and is highly durable in seawater and chemical processing conditions.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@georgemetals.us
Yes, Titanium Grade 12 exhibits remarkable high-temperature resistance, making it suitable for use in power generation and industrial processes that involve elevated temperatures.
Titanium Grade 12 bars and rods are widely used in applications that call for moderate strength and exceptional corrosion resistance. They work especially well in heat exchangers, piping systems, and chemical processing equipment that are exposed to hot, saline, or acidic conditions. Because of its exceptional resistance to seawater corrosion, Grade 12 is ideal for desalination systems, offshore oil and gas platforms, and marine hardware. It also offers long-term performance and dependability in industrial scrubbers, power generation facilities, and aerospace structures. It is adaptable for custom-fabricated components due to its formability and weldability.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
George Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Houston, USA
