Based in Chennai, India, Vinit Stainless is a well-known producer and supplier of titanium gr 11 forgings, providing top-notch goods to a range of international industries. Vinit Stainless has established itself as a reputable brand in the titanium forging industry by placing a high value on accuracy, quality, and longevity. To satisfy the most exacting industrial requirements, our Titanium Grade 11 forgings are made with cutting-edge technology and in accordance with international standards. We are a preferred partner for sectors like power generation, chemical processing, aerospace, and marine because we deliver solutions on time and with customised solutions that meet client specifications.
In order to improve corrosion resistance, particularly in reducing environments, titanium Gr 11 forgings—a modified form of Grade 1 titanium—are stabilised with a tiny addition of palladium (0.12–0.25%). Titanium (balance), oxygen (maximum 0.18%), iron (maximum 0.20%), nitrogen (maximum 0.03%), hydrogen (maximum 0.015%), and carbon (maximum 0.08%) make up its usual composition. A tensile strength of roughly 345 MPa, a yield strength of 275 MPa, and exceptional ductility with elongation exceeding 24% are among its mechanical attributes. This alloy is perfect for crucial industrial applications needing corrosion resistance because it maintains excellent formability and weldability.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 11 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | 12 – .25 |
| Grade | Tensile Strength min | Yield Strength (0.2 % Offset) | Elongation | Reduction of Area | ||
| ksi | Mpa | ksi | Mpa | min % | min % | |
| 11 | 35 | 240 | 25 | 170 | 24 | 30 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52550 |
Yes, Titanium Gr 11 forgings are highly corrosion-resistant, especially to oxidizing environments and seawater. This makes them ideal for applications in industries like aerospace, marine, and chemical processing, ensuring long-lasting durability.
Titanium Gr 11 forgings are commonly used in industries such as aerospace, marine, chemical processing, medical, and power generation. Their strength, corrosion resistance, and high-performance capabilities make them ideal for demanding applications.
Yes, Titanium Gr 11 forgings can be customized for specific applications, offering tailored sizes, shapes, and properties to meet unique industry requirements, ensuring optimal performance and reliability in demanding environments.
In industries where outstanding corrosion resistance is essential, particularly in mildly reducing environments, titanium Gr 11 forgings are widely used. They are perfect for pulp and paper manufacturing components, heat exchangers, desalination plants, marine hardware, and chemical processing equipment. These forgings are appropriate for coastal and offshore applications because of their superior resistance to brine and chlorides. They are also useful in the defence and aerospace industries due to their strength-to-weight ratio and weldability. Titanium Gr 11 forgings provide long-term durability and low maintenance, making them an affordable solution for demanding service conditions in power generation, particularly in nuclear and hydro-based systems.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
