Based in Houston, Texas, George Metals is a specialized manufacturer dedicated to providing high-performance titanium flat bars for a range of industrial uses. We provide products that satisfy exacting requirements in terms of grade, size, and finish thanks to our proficiency in titanium engineering. Our titanium flat bars are renowned for their remarkable durability, corrosion resistance, and strength-to-weight ratio. These bars are perfect for crucial applications in the automotive, chemical processing, medical, marine, and aerospace industries because they are manufactured in compliance with stringent industry standards. Every flat bar at George Metals is designed for optimal performance, dependability, and long-term operational efficiency.
Depending on the use, titanium flat bars are rectangular solid bars composed of either commercially pure titanium or titanium alloys. Grade 2, which is made up of roughly 99% pure titanium, offers exceptional formability and corrosion resistance, making it perfect for settings with lower structural requirements. Made of 90% titanium, 6% aluminum, and 4% vanadium, Grade 5 (Ti-6Al-4V) provides exceptional strength, toughness, and fatigue resistance. These bars are stable in corrosive and high-temperature conditions and usually exhibit a tensile strength between 400 and 900 MPa. They are crucial in high-performance industrial settings because of their mechanical strength and light weight.
| Standard | ASTM B348, ASME B348, ASTM B863, ASTM F67, ASTM F136 |
| Application | Industrial and Medical |
| Shape | Flat |
| size | Dia 5.0~350 X ≤ 6000 |
| Grade | Gr1, Gr2, Gr3, Gr4, Gr5, Gr7,Gr23,Ti15333 |
| Density | 4.53 g/cm3 |
| Techniques | Forged,Rolled, Extrusion |
| Surface | Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline |
| Technique | TC4 Titanium Alloy Hot Rolled, Cold Rolled, Cold Drawn, Forged |
Hardness, Brinell | 120 | 120 | annealed |
Hardness, Knoop | 132 | 132 | Estimated from Brinell. |
Hardness, Rockwell B | 70 | 70 | annealed |
Hardness, Vickers | 122 | 122 | Estimated from Brinell |
Tensile Strength, Ultimate | 240 MPa | 34800 psi | – |
Tensile Strength, Yield | 170 – 310 MPa | 24700 – 45000 psi | – |
Elongation at Break | 24 % | 24 % | – |
Reduction of Area | 35 % | 35 % | – |
Modulus of Elasticity | 105 GPa | 15200 ksi | In Tension |
Compressive Modulus | 110 GPa | 16000 ksi | – |
Poisson’s Ratio | 0.37 | 0.37 | – |
Charpy Impact | 310 J | 229 ft-lb | V-notch |
Shear Modulus | 45 GPa | 6530 ksi | – |
|
Physical Properties |
Metric |
English |
|
Density |
4.51 g/cc |
0.163 lb/in³ |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51 g/cc | 0.163 lb/in³ |
|
STANDARD |
WERKSTOFF NR. |
UNS |
|
Titanium |
3.7035 / 3.7165 / 3.7235 |
R50400 / R56400 / R52400 |
Titanium Flat Bars are commonly used in the aerospace, medical, and chemical industries for components like frames, brackets, and heat exchangers due to their strength and corrosion resistance.
Yes, Titanium Flat Bars can be welded, but they require precise control over heat to avoid contamination and maintain the material’s strength and corrosion resistance.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@georgemetals.us
Applications requiring strength, resistance to corrosion, and low weight frequently use titanium flat bars. They are utilized in the aerospace industry for fasteners, aircraft parts, and structural elements. Because of their resistance to seawater, they are used in the marine industry in shipbuilding, offshore platforms, and underwater equipment. Their biocompatibility for prosthetics, implants, and surgical instruments is advantageous to the medical industry. They are used in the production of valves, reactor vessels, and heat exchangers by the chemical processing industries. They are also used in energy, defense, and automotive applications, particularly in situations where durability in challenging conditions and dependability under pressure are essential.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
George Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Houston, USA
