Reputable high-performance metal product manufacturer and supplier George Metals, with headquarters in Midland, USA, provides precisely engineered solutions to international industries. Super Duplex Steel S32760 Forgings, one of the company’s main products, are renowned for their remarkable resistance to corrosion, high tensile strength, and resilience in challenging conditions. These forgings are perfect for crucial parts like pressure vessels, heat exchangers, valves, and pumps because they are made to satisfy the exacting specifications of sectors like petrochemicals, chemical processing, oil and gas, and marine. George Metals is dedicated to providing dependable products with a long service life that resist pitting and stress corrosion.
About 26% chromium, 6% nickel, 1.2% molybdenum, 0.2% nitrogen, and trace amounts of manganese, silicon, and carbon make up Super Duplex Steel S32760 forgings. Because of its composition, the alloy exhibits exceptional resistance to stress corrosion cracking, crevice corrosion, and pitting caused by chloride, which makes it ideal for harsh environments. In terms of mechanical properties, it combines strength and toughness with yield strength of 600–800 MPa, tensile strength of 800–1100 MPa, and elongation of up to 25%. Because of these characteristics, S32760 forgings are perfect for corrosive, high-pressure settings where material failure is not an option.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32760 | 1.4501 | S32760 |
Yes, Super Duplex Steel S32760 forgings are highly suitable for offshore and marine applications due to their excellent corrosion resistance, high strength, and resistance to pitting, crevice corrosion, and chloride stress cracking.
Welding processes compatible with Super Duplex Steel S32760 forgings include Tungsten Inert Gas (TIG), Metal Inert Gas (MIG), and Shielded Metal Arc Welding (SMAW), using matching filler materials to maintain corrosion resistance.
Super Duplex Steel S32760 forgings are governed by ASTM A182, ASTM A240, ASME SA-182, and EN 10088-3 standards, ensuring quality, corrosion resistance, and mechanical properties for demanding industrial applications.
S32760 Super Duplex Steel Industries that demand a combination of high strength, corrosion resistance, and dependability make extensive use of forgings. They are used in pipeline systems, offshore platforms, and subsea equipment in the oil and gas industry, where resistance to chloride corrosion is essential. They are employed in the maritime sector for piping and structural systems in saltwater settings. These forgings are perfect for heat exchangers, pumps, valves, flanges, and pressure vessels in chemical processing and desalination facilities. In the most demanding industrial applications, their resilience to high pressure and corrosive environments guarantees dependable, long-term service.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
