A prominent producer and supplier of stainless steel goods, George Metals provides a variety of parts, including plates, pipes, poles, and most notably, hex bars and rods. One of the leading producers of SS Hex Bar and Rod in India, we create premium goods in a variety of sizes, shapes, and grades to meet a broad range of industrial needs. The main applications for our stainless steel hex bars are fasteners, structural reinforcements, and construction. Variants with molybdenum added, such as ASTM A479., are also designed for use in corrosive and marine environments. George Metals provides performance, accuracy, and quality for all requirements.
High-grade alloys such as 304, 316, and 410, which combine iron, chromium (10–30%), nickel (up to 35%), carbon, manganese, and silicon, are commonly used to make stainless steel hex bars and rods. These compositions provide outstanding mechanical strength, oxidation resistance, and corrosion resistance. With elongation of about 40% and tensile strength of up to 1000 MPa, depending on the grade, strength and flexibility are guaranteed. Because of these characteristics, stainless steel hex bars are ideal for use in a variety of industrial sectors where they must withstand loads, high temperatures, and corrosive conditions.
| Name | Stainless Steel Hexagonal Bars |
| Stainless Steel Hex Bar Standard | EN, AISI, DIN, ASTM, SUS |
| Grades | 304L, 201, 202, 301, 304LN, 309S, 17L, 347, 347H, 316N, 316LN, 304, 316, 316L, 317,3 304N 310S, 316Ti, |
| Stainless Steel Hex Bar Size (Hexagonal bar) | 6 x 6 milimeter to 75 x 75 milimeter |
| Shape | Stainless steel hexagonal bar |
| Price Term | CIF/FOB/CNF or as per need |
| Stainless Steel Hex Bar Length | 5MTR, 4MTR, 6MTR, 3MTR or as per need |
| Application | Architectural Applications, Kitchen Equipment , Sanitary Wares, Furniture, Precision Engineering |
| Stainless Steel Hex Bar Certificate | NDT Test Reports, NABL Approved Lab Test Reports, IGC Practice E Test Reports, Mill TC EN 10204 3.1, |
| Grade | Si | C | Mn | Cr | Ni | N | S | P |
| SS 304 | 0.75 max | 0.03 max | 2 max | 18 – 20 | 8 – 12 | 0.10 Max | 0.030 max | 0.045 max |
| SS 304L | 0.75 max | 0.03 max | 2 max | 18 – 20 | 8 – 12 | 0.10 Max | 0.030 max | 0.045 max |
| SS 316 | 0.75 max | 0.08 max | 2 max | 15 – 18 | 10 – 14 | 0.1 Max | 0.030 max | 0.045 max |
| SS 316L | 0.75 max | 2.00 max | 18.00 max | 14.00 Max | 0.10 Max | 0.1 Max | 0.030 max | 0.045 max |
| Grade | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Density | Melting Point |
| SS 304 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40% | 8.0 g/cm3 | 1400 °C (2550 °F) |
| SS 304L | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40% | 8.0 g/cm3 | 1400 °C (2550 °F) |
| SS 316 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % | 8.0 g/cm3 | 1454 °C (2650 °F) |
| SS 316L | 485 Min | 170 Min. | 40 % | 8.0 g/cm3 | 1400 °C (2550 °F) |
| Length in inch | Size in Inch | Weight (lbs/ft) |
|---|---|---|
| 144 | 1/4 | .180 |
| 3/8 | .415 | |
| 7/16 | .565 | |
| 1/2 | .735 | |
| 9/16 | .930 | |
| 5/8 | 1.15 | |
| 11/16 | 1.390 | |
| 3/4 | 1.655 | |
| 7/8 | 2.255 | |
| 1 | 2.945 | |
| 1-1/16 | 3.31 | |
| 1-1/8 | 3.73 | |
| 1-1/4 | 4.60 | |
| 1-3/8 | 5.58 | |
| 1-1/2 | 6.63 | |
| 1-5/8 | 7.78 | |
| 2 | 11.79 | |
| 4 | 47.160 |
| Sizes in Inch | Stainless Steel Hex Bar Sizes In inch |
| H-1/8 | 1/8 |
| H-1/4 | 1/4 |
| H-5/32 | 5/32 |
| H-3/16 | 3/16 |
| H-7/32 | 7/32 |
| H-5/16 | 5/16 |
| H-3/8 | 3/8 |
| H-7/16 | 7/16 |
| H-7/8 | 7/8 |
| H-1/2 | 1/2 |
| H-9/16 | 9/16 |
| H-5/8 | 5/8 |
| H-11/16 | 11/16 |
| H-3/4 | 3/4 |
| H-1 | 1 |
| H-1-1/8 | 1-1/8 |
| H-1-1/4 | 1-1/4 |
| H-2 | 2 |
| H-1-3/8 | 1-3/8 |
| H-1-1/2 | 1-1/2 |
| H-1-5/8 | 1-5/8 |
| H-1-3/4 | 1-3/4 |
| H-1-7/8 | 1-7/8 |
| H-2-1/4 | 2-1/4 |
| H-2-3/4 | 2-3/4 |
| H-2-1/2 | 2-1/2 |
| H-3 | 3 |
| Section | Size, diameter | Permitted overall variation | ||
| Class A | Class B | Class C | ||
| mm | mm | mm | mm | |
| Round | ≧ 6 <75 | 0.05 | 0.025 | 0.013 |
Stainless steel hex bars and rods come in various grades, including 304, 316, 410, 416, 420, and 630. They vary in corrosion resistance, strength, and hardness. Common types include austenitic, ferritic, martensitic, and precipitation-hardening stainless steels, each suited for different applications in manufacturing, construction, and marine environments.
In the USA, you can buy high-quality stainless steel (SS) hex bars and rods from suppliers such as Metal Supermarkets, 304 Stainless Steel, or Aalco Metals. They offer a wide selection of sizes and grades. Other reputable suppliers include Buy Metal Online, Steel Express, and USA Steel. Ensure to check their specifications for the exact product you need.
Yes, many USA suppliers offer 316 stainless steel hex bars and rods in custom sizes and finishes. Companies like Metal Supermarkets, Buy Metal Online, and Steel Express provide tailored options, including specific lengths, diameters, and polished finishes. Contacting the supplier directly allows you to request personalized products to meet your specific requirements for projects.
Because of their strength, durability, and resistance to corrosion, stainless steel hex bars and rods are used extensively in the automotive, aerospace, marine, and construction industries. Bolts, nuts, fasteners, shafts, machine parts, and reinforcement rods for structural frameworks are among the common uses. These bars are also necessary in food processing facilities, chemical plants, and marine equipment where oxidation, moisture, or chemicals are frequently encountered. Stainless steel hex bars are highly versatile and dependable, providing long-lasting performance and service life in heavy-duty machinery operating in harsh environments, custom fabrications, and piping systems.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
George Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Houston, USA
