Based in Houston, Texas, George Metals is a reputable producer and supplier of premium stainless steel 904L bars and rods. With years of experience in the field and a dedication to quality, we provide high-end corrosion-resistant solutions for a variety of industrial uses. Our 904L stainless steel bars and rods are designed to satisfy international quality standards, guaranteeing exceptional performance in demanding conditions. George Metals is a preferred supplier for customers in the chemical processing, marine, oil and gas, and other demanding industries because we place a high premium on customer satisfaction, precision engineering, and on-time delivery.
The composition of stainless steel 904L bars and rods is low (≤0.02%) and includes 19–23% chromium, 23–28% nickel, 4–5% molybdenum, and 1-2 percent copper. In challenging conditions, this super austenitic stainless steel provides exceptional resistance to pitting and corrosion. Its elongation is 35% (min), its yield strength is 220 MPa (min), and its tensile strength is 490 MPa (min). The alloy is perfect for demanding applications because of its non-magnetic properties and resilience. 904L offers a special combination of strength, weldability, and corrosion resistance while maintaining mechanical integrity even at high temperatures.
| Grade | SS 904L – UNS N08904 |
|---|---|
| Specification | ASTM A276 UNS N08904, WS 1.4539, AFNOR Z2CNDU 25-20 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 904Lmm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Round Bar Standard Dimensions | Diameter / Height: |
| Finish | Cold (bright) drawn, centreless ground,smooth turned, peeled, slit rolled edge, hot rolled, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | Stainless Steel 904L Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | Stainless Steel 904L Welding Rod, Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Our stockyad location for fast delivery across India | Coimbatore, Bhubaneswar, Ahmedabad, Bengaluru, Thiruvananthapuram, Agra, Chennai, Noida, Mumbai, Shivamogga, Dhanbad, Hyderabad, Tiruchirappalli, Tirunelveli, Pune, Pimpri-Chinchwad, Navi Mumbai |
| Our Stainless Steel 904L Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|---|
| SS 904L | 0.020 max | 2 max | 1 max | 0.040 max | 0.030 max | 19.0-23.0 | 4.0-5.0 max | 23.00 – 28.00 | 1.0-2.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35% |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Stainless Steel 904L is a high-alloy, corrosion-resistant material that contains significant amounts of nickel, chromium, and molybdenum. It is designed for use in highly corrosive environments, offering excellent resistance to acids, particularly sulfuric acid, and chloride corrosion. It is commonly used in chemical processing, marine, and pharmaceutical industries.
The key benefits of Stainless Steel 904L Bars and Rods include exceptional resistance to corrosion, excellent weldability, and good formability. These properties make them ideal for applications in aggressive chemical environments, marine applications, and other high-performance settings.
Because of their exceptional resistance to acid attacks and pitting, stainless steel 904L bars and rods are widely used in extremely corrosive environments. Chemical processing facilities, pharmaceutical companies, oil refineries, and marine environments—particularly those exposed to chlorides and acidic conditions—all use these rods. They are also utilised in seawater cooling devices, gas scrubbing systems, pulp and paper industries, and heat exchangers. They are also appropriate for structural and architectural components due to their exceptional formability and high strength. 904L is a dependable material in crucial engineering projects because of its resistance to high temperatures and pressures.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
