Houston-based USA company George Metals is a trusted producer and supplier of **Stainless Steel 446 Square Bars and Rods**, which are renowned for supplying heat- and corrosion-resistant products designed to meet the tough industrial conditions. Stainless Steel 446 is a ferritic stainless steel with excellent oxidation and scaling resistance at high temperatures and is thus appropriate for high-temperature and thermal structural uses. George Metals provides accurate manufacturing, precise surface finish, and dimensions. These stainless steel square bars and rods find best application in furnace parts, petrochemical processing equipment, as well as in power generation plants where both thermal stability and corrosion resistance are very important.
**SS 446 Square Bars and Rods** usually have 23–27% chromium content with very low carbon (≤0.20%) and minor addition of molybdenum, silicon, manganese, and sulfur. The high chromium composition gives excellent oxidation resistance in atmospheres up to 1100°C. Mechanical properties are tensile strength of 485–620 MPa, yield strength approximately 275 MPa, and elongation of 20–25%. The product, **Stainless Steel 446 Square Bars/Rods**, is heat treatment non-hardenable but provides superior thermal fatigue resistance, dimensional stability, and durability in sulfur-rich or high-temperature environments.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 446 | 0.2 | 23.00 | 1.5 | 0.50 | 0.040 | 0.030 | 0.75 |
| Element | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness (Brinell (HB) max) |
| SS 446 | Psi – 75,000 , MPa – 485 | Psi – 40,000 , MPa – 275 | 20 % | – |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 446 | 1.4762 | S44600 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
