George Metals, Houston, USA, is a trusted maker and supplier of **Stainless Steel 440C Bars and Rods**, which offer high-strength, wear-resistant applications to industries that demand precision and durability. 440C, with its high carbon and chromium content, is a martensitic stainless steel that provides the highest hardness and strength when heat-treated among stainless grades. George Metals provides close dimensional tolerances, smooth surface finish, and consistent quality, rendering these bars and rods appropriate for extreme applications within the aerospace, medical, tooling, and mechanical engineering industries, where wear resistance, edge holding, and load carrying are critical.
**Stainless Steel 440C Bars and Rods** consist of 16–18% chromium, 0.95–1.20% carbon, and trace elements of manganese, molybdenum, and silicon. This structure enables the steel to attain remarkable hardness (up to 58–60 HRC) and satisfactory corrosion resistance in mild surroundings. Mechanical properties are tensile strength of 760–1000 MPa, yield strength of 450–600 MPa, and average ductility. The product, **Stainless Steel 440C Bars/Rods**, possesses a renowned wear resistance, retention of edge, and mechanical strength, particularly following heat treatment, and is highly suitable for applications where toughness and surface durability are needed.
| Specification | ASTM A479/ SA479 ASTM A276/ ASME SA276 |
|---|---|
| Grade | Stainless Steel 440C (UNS S44004) |
| Hex Bar size | 18 to 57mm (11/16″ – 2-3/4″) |
| Round bar size | OD 4mm to 500mm |
| Square bar size | 18mm to 47mm (11/16″- 1-3/4″) |
| Billet Size | 1/2″- 495mm Dia. |
| Rectangles Size | 33 x 30mm – 295 x 1066mm |
| Bright Bar | OD 4mm to 100mm |
| Tolerance | K12 H12, K10, H9, H11, H8, H13K9, H10, K11, or as per need |
| Flat bar size | 1/2” to 10” in thickness of 2 to 150mm |
| Angle bar size | 3*20*20~12*100*100 |
| Finish | centreless ground, Cold (bright) drawn, hot rolled, peeled, smooth turned, hot rolled annealed, slit rolled edge, Bright, Rough Turned, Grinding, Polish & Black |
| Form | Flat Bar, Hollow, Round, Square, Triangle, Rectangle, Half Round Bar, Rod, T-Bar, Precision Ground Bar, Hex (A/F), Blocks, Channel Bar, Threaded, Round Rod, Billet, Profiles, I/H Bar, Ingot, Rings, Forging etc. |
| Technique | 440C Stainless Steel Hot Rolled, Cold Drawn, Rod, Forged Round Bar, Cold Rolled |
| Condition | annealed, Hardened & tempered |
| Section | 3.0 -12.0 mm thickness, 80 x 40 to 150 x 75mm section |
| Channel Bar | 5.0 – 6.0mm thickness |
| Surface | Bright, Cold Drawn, Hot Rolled Pickled, Sand Blasting Finished, Polished, Hairline |
| Hollow Bar | 32mm OD x 16mm ID – 250mm OD x 200mm ID |
|
SS 440C |
Min |
Max |
|---|---|---|
|
Si |
– |
1.00 |
|
C |
0.95 |
1.20 |
|
Mo |
0.00 |
0.75 |
|
P |
– |
0.04 |
|
Ni |
– |
1.00 |
|
Mn |
– |
1.00 |
|
Cr |
16.00 |
18.00 |
|
S |
0.15 |
0.03 |
|
Element |
SS 440C |
|---|---|
|
Tensile (UTS)N/mm² |
1965 |
|
Temp°C |
20 |
|
Reductionof Area |
10 |
|
Elongation(50.8mm) %) |
2 |
|
0.2% YieldN/mm² |
1896 |
|
HardnessHRc |
57 |
|
STANDARD |
UNS |
WERKSTOFF NR. |
JIS |
|---|---|---|---|
|
SS 440C |
S44004 |
1.4125 |
SUS 440C |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
