Based in Houston, Texas, George Metals is a top producer and supplier of 420 Hex Bars of stainless steel, offering precisely engineered stainless steel products to a wide range of industries. George Metals is well-known for their dedication to quality, dependability, and prompt delivery. They offer 420 hex bars that satisfy exacting industry standards. These bars are renowned for their ease of machining, moderate resistance to corrosion, and exceptional hardness. George Metals guarantees that every product is manufactured with strict quality control, making it ideal for applications requiring wear resistance and good surface finish. It provides unparalleled consistency and value to industries such as industrial equipment, automotive, medical, and tooling.
Stainless Steel 420 Hex Bars are made of martensitic stainless steel, which has a chromium content of 12–14% and a carbon content of up to 0.15%. Manganese, silicon, and sulphur are added in trace amounts. The alloy has moderate corrosion resistance, high hardness, and is heat-treatable. Following hardening, 420 can reach a Rockwell hardness of 50–55 HRC and a tensile strength of about 700–800 MPa. When annealed, it has good ductility and can be polished to a high sheen. 420 is renowned for its strength, durability, and economical performance in a range of mechanical and cutting applications. It is also magnetic under all circumstances.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 420 | 0.15 | 14.0 | 1.00 | – | 0.04 | 0.03 | 1.00 |
| Element | Tensile Strength | Yield Strength | Elongation | Hardness |
| SS 420 | 95,000 | 50,000 | 25 | 175 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Applications requiring high hardness and moderate corrosion resistance frequently use stainless steel 420 Hex Bars. The production of surgical instruments, cutlery, pump shafts, valve components, and machine parts are among the frequently used applications. Because of their strength and machinability, these hex bars are preferred in sectors like petrochemical, industrial tooling, medical, and automotive. 420 hex bars are perfect for parts that are subjected to friction or contact stress because they perform well under wear and abrasion when hardened and tempered. They are also appropriate for precision-finished or aesthetically pleasing components due to their ability to achieve a bright polish.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
George Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Houston, USA
