A reputable manufacturer and supplier in Houston, Texas, George Metals provides a high-end selection of stainless steel 420 bars and rods that are designed for longevity, performance, and resistance to corrosion. George Metals, which specialises in premium stainless steel products, supplies important industries like tool manufacturing, engineering, automotive, and medicine. Superior mechanical qualities and exact dimensional tolerances are guaranteed by their production of stainless steel 420 bars and rods, which strictly adheres to international standards and quality specifications. These bars, which are well-known for their exceptional polishability and moderate resistance to corrosion, come in a range of sizes and finishes to accommodate a variety of industrial applications while maintaining dependable performance and affordable prices.
Stainless Steel 420 Bars/Rods are martensitic stainless steel with trace amounts of silicon, manganese, phosphorus, sulphur, and 0.15–0.40% carbon and 12–14% chromium. Because of its composition, the alloy can undergo heat treatment to increase its hardness, reaching Rockwell hardness of up to 50 HRC and tensile strength of up to 700–800 MPa. 420 has outstanding polishability and moderate corrosion resistance in mild conditions. Its mechanical and chemical properties, particularly after hardening and tempering, make it appropriate for uses requiring a high level of surface finish and moderate strength.
| Specification | ASTM A276/ A479, ASME SA276/SA479 |
|---|---|
| Grade | Stainless Steel 420 (UNS S42000) |
| Flat bar size | 1/2” to 10” in thickness range of 2mm to 150mm |
| Square bar size | 18mm – 47mm (11/16″ to 1-3/4″) |
| Round bar size | Outside Diameter in the range of 4mm to 500mm |
| Hex Bar size | 18mm – 57mm (11/16″ to 2-3/4″) |
| Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular bar Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | 420 Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Processing | Bar cutting to 650mm |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Our 420 Stainless Steel Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | Si | P | S | Cr | |
| 420 | min. | – | – | – | – | – | 12.0 |
| max. | 0.15 | 1.0 | 1.00 | 0.04 | 0.03 | 14.0 | |
| Grade | Tensile Strength (ksi) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (ksi) min | Hardness |
| 420 | 95,000 | 25 | 50,000 | 175 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 420 | 1.4021 | S42000 | SUS 420 J1 | 420S29 | – | – | FeMi35Cr20Cu4Mo2 |
A wide range of applications requiring high hardness, polishability, and moderate corrosion resistance use stainless steel 420 bars and rods. Cutlery, dental and surgical tools, pump shafts, valve parts, scissors, and machine parts are among the frequently used items. For parts that need a long-lasting and easily sharpened edge, the manufacturing, automotive, and medical sectors favour 420. It is appropriate for precision components that are subjected to wear and abrasion because it can be hardened through heat treatment. 420’s bright finish and resistance to atmospheric conditions make it a reliable material for long-term use in decorative or utility applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
