Located in Houston, Texas, George Metals is a reputable manufacturer and supplier of high-quality stainless steel 416 square bars and rods that are made to satisfy a variety of industrial needs. These bars are well known for their consistent performance and outstanding machinability, making them perfect for high-volume production settings. George Metals offers SS 416 square bars that are produced in accordance with international standards and come in a variety of sizes and finishes. The company serves industries like automotive, defence, and machinery with an emphasis on accuracy, robustness, and customer satisfaction. They have established a strong reputation in both domestic and foreign markets thanks to their dedication to on-time delivery and quality control.
Martensitic stainless steels, such as stainless steel 416 Square Bars/Rods, are typically composed of 12–14% chromium, 0.15% carbon, and additional sulphur for better machinability. When annealed, this free-machining alloy has a Brinell hardness of about 200 HB and a tensile strength of up to 700 MPa. In addition to being magnetic, it can be heated to increase its hardness and strength. Although it is not as resistant to corrosion as austenitic grades, it is sufficient for mild conditions. One of the easiest stainless steels to machine is SS 416 because of its exceptional machinability.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 416 | 0.15 | 14.0 – 12.0 | 1.25 | – | 0.06 | 0.15 | 1 |
| Element | Density, lb/in3 | Melting Point | Electrical Resistivity |
| SS 416 | 0.282 lbs/in3 7 .80 g/cm3 | 2700 – 2790 °F (1488 – 1530 °C) | At 70 °F (21 °C): 343.0 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 416 | 1.4005 | S41600 | SUS 416 | 416S21 | – | – | X12CrS13 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
In industries where machinability is a crucial requirement, stainless steel 416 square bars and rods are widely used. They are perfect for producing fasteners, valve parts, bolts, screws, and gears. The material is frequently used for parts that need high precision and moderate corrosion resistance in the pump and valve, industrial machinery, and automotive industries. Additionally, SS 416 is appropriate for shafts, axles, and fittings where moderate strength and high-speed machining are crucial. 416 is an affordable choice for high-volume, tight-tolerance machining operations because of its magnetic qualities and simplicity of fabrication.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
