Varun Sheets and Plates is a reliable manufacturer and supplier of stainless steel products of high quality in Dubai, UAE, with a keen interest in providing high-performance, durable materials to numerous industries. Our Stainless Steel 410 Hex Bar is among our most popular products, recognized for its remarkable mechanical properties and resistance to corrosion. Manufactured from high-quality raw materials and sophisticated manufacturing processes, our SS 410 Hex Bars are made to sustain the requirements of engineering, construction, and industrial processes. We maintain accuracy, strength, and reliability in each bar to accommodate intense operations in demanding conditions.
Stainless Steel 410 Hex Bar is a martensitic stainless steel with about 11.5–13.5% chromium, 0.75% nickel, and up to 0.15% carbon content, with trace amounts of manganese, silicon, and sulfur. It provides a minimum tensile strength of 450 MPa, yield strength of 205 MPa, and elongation of about 20%. Having a maximum hardness of about 223 HB in the annealed condition, SS 410 Hex Bar is characterized by good strength, toughness, and moderate corrosion resistance. It is thus ideally suited for wear and durability components subjected to mild corrosive environments.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 410 | 0.15 | 11.5-13.5 | 1.00 | 0.75 | 0.040 | 0.030 | 1.00 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
