Varun Sheets and Plates is a top stainless steel producer and distributor in Dubai, UAE, providing comprehensive-grade materials for commercial and industrial uses. Among their specialty products is the Stainless Steel 317L Flat Bar, which is famous for its high resistance against corrosion and remarkable performance in harsh chemical conditions. Carefully designed with precision and manufactured to international specification, Varun Sheets and Plates provides unwavering quality, toughness, and reliability. Their Stainless Steel 317L Flat Bars find extensive application in the chemical, marine, pharmaceutical, and food processing sectors in the Middle East and other regions.
Stainless Steel 317L Flat Bar is a molybdenum-containing austenitic stainless steel with low carbon and is made up of around 18–20% chromium, 11–15% nickel, and 3–4% molybdenum. The lower content of carbon improves weldability and reduces the risk of intergranular corrosion. It provides a tensile strength of approximately 515 MPa and a yield strength of 205 MPa. Stainless Steel 317L Flat Bar is particularly prized for its ability to resist sulfuric acid, chlorides, and other hard chemicals, and it finds itself an even better alternative in applications that need strength as well as corrosion resistance.
Standard ASTM A276, A479 / ASME SA276, SA479
Range 3.17 MM TO 350 MM DIA
Diameter 25mm to 152mm
Size Tolerance h8, h9(DIN 671), h10, h11, ASTM A484, DIN 1013
Finish Bright, Polish & Black
Form Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wiremesh, Billet, Ingot, Forging Etc.,
Condition Cold Drawn & Polished Cold Drawn, Centreless Ground & Polished
Other Services Machining (CNC), Centreless Grinding (CG), Heat Treatment, Anneling, Pickling, Polish, Rolling, Forging, Cutting, Bending, Minor Fabrication
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317L | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.845 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
|---|---|---|---|---|
| SS 317L | 1.4449 | S31700 | SUS 317 | – |
Stainless Steel 317L Flat Bar is widely used in extremely corrosive environments where normal stainless steels will fail. It is widely used in chemical processing plant equipment, pulp and paper mills, marine and coastal buildings, food and drink processing, and pharmaceutical plants. The flat bar shape is best suited for structures, structural shapes, bracing, and supports. Its high resistance to pitting, crevice corrosion, and stress corrosion cracking recommends it for tanks, heat exchangers, evaporators, and process piping. The durability of the material provides long service life in adverse and corrosive environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
