Luke Steel Manufacturers and Suppliers, based in Houston, USA, are your go-to experts for top-notch Stainless Steel 316L forgings. Known for its outstanding corrosion resistance and mechanical strength, 316L is a low-carbon type of stainless steel that really shines in tough and corrosive settings. With cutting-edge forging techniques, Luke Steel ensures that every component meets the highest industry standards. They cater to various sectors, including marine, chemical processing, and pharmaceuticals, providing durable and reliable solutions that are customized for specific needs, all while prioritizing precision, quality, and customer satisfaction.
Stainless Steel 316L is a low-carbon alloy enriched with molybdenum, containing about 16-18% chromium, 10-14% nickel, and 2-3% molybdenum. This unique blend boosts its resistance to pitting, crevice corrosion, and stress corrosion cracking caused by chlorides. It boasts a tensile strength of around 485 MPa and a yield strength of about 170 MPa, with an impressive elongation of 40%. Thanks to its excellent mechanical properties and weldability, it’s a top choice for demanding applications that require both corrosion resistance and strength, especially in environments where acids, salts, and extreme temperatures are present.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Stainless Steel 316L forgings are essential in industries that demand exceptional corrosion resistance and durability. In the marine industry, you’ll find them in fittings, shafts, and fasteners that are constantly exposed to saltwater. The chemical and pharmaceutical sectors rely on 316L for reaction vessels, tanks, and piping because of its ability to withstand acidic and chloride-rich conditions. Its biocompatibility makes it a perfect fit for surgical instruments and implants in the medical field. Plus, its strength and visual appeal make it a great choice for architectural elements and food processing equipment, showcasing its versatility across a wide range of applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
