Varun Sheets and Plates is a leading stainless steel producer and distributor in Dubai, UAE, providing high-performance materials specifically designed for demanding industrial uses. Included among their high-tech products is the **Stainless Steel 316Ti Forgings**, which was developed to offer improved corrosion resistance and mechanical strength, particularly under high-temperature and aggressive chemical conditions. With an adherence to global standards and state-of-the-art manufacturing facilities, Varun Sheets and Plates caters to a wide range of industries such as marine, petrochemical, food processing, and pharmaceuticals in the Middle East and overseas.
**Stainless Steel 316Ti Forgings** consist of 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and a minor addition of titanium (usually around 0.5%) for stabilization against intergranular corrosion. These forgings possess a tensile strength of about 550 MPa and a yield strength of about 240 MPa. The addition of titanium provides improved resistance to sensitization on welding and higher temperature exposure, which renders the 316Ti condition capable of continuous service up to 870°C. Stainless Steel 316Ti Forgings possess improved toughness, formability, and corrosion resistance in acidic and chloride environments as well.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316Ti | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
