Varun Sheets and Plates is one of the top stainless steel producers and suppliers from Dubai, UAE, renowned for providing high-quality materials conforming to global quality standards. One of its best-selling items is the **Stainless Steel 316Ti Bar/Rod**, specifically tailored for application in high-temperature and corrosive conditions. With a strong emphasis on product reliability, precision engineering, and timely delivery, Varun Sheets and Plates supplies various industries such as petrochemical, marine, pharmaceutical, and food processing in the Middle East and around the world.
**Stainless Steel 316Ti Bar/Rod** is an austenitic stainless steel alloy with 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and added titanium for stabilization. The addition of titanium avoids sensitization and intergranular corrosion on welding and long-term high-temperature treatment. It offers a tensile strength of around 550 MPa and yield strength of 240 MPa. Stainless Steel 316Ti Bar/Rod possesses superior corrosion resistance in environments rich in chlorides and in acids, combined with good mechanical strength and excellent weldability.
Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Specification : ASTM A276, A479 / ASME SA276, SA479
Hex Bars : 18mm – 57mm (11/16″ to 2-3/4″)
Square Bars : 18mm – 47mm (11/16″ to 1-3/4″)
Round Bars : Outside Diameter in the range of 4mm to 500mm
Bright Bars : Outside Diameter in the range of 4mm to 100mm
Length : 1 to 6 Meters, Custom Cut Lengths
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Form : Round, Square, Hex (A/F), Rectangle Etc.
|
C |
Ni |
Mn |
P |
S |
Si |
Cr |
Mo |
|
|---|---|---|---|---|---|---|---|---|
|
MIN |
0.040 |
10.000 |
– |
– |
– |
– |
16.000 |
2.000 |
|
MAX |
0.100 |
14.000 |
2.000 |
0.040 |
0.030 |
1.000 |
18.000 |
3.000 |
|
Yield Strength
0.2% Proof
(MPa) |
Tensile strength
(MPa)
|
Elongation
(% in 50mm) |
Hardness (HRB) | |
|---|---|---|---|---|
|
MIN |
170 |
485 |
40.00 |
|
|
MAX |
95 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | BS | AFNOR | EN |
| SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 08Ch17N13M2T | 320S31 | Z6CNDT17‐12 | X6CrNiMoTi17-12-2 |
Stainless Steel 316Ti Bar/Rod is extensively applied where higher corrosion resistance, thermal stability, and structure strength are desired. Typical applications are heat exchanger tubes, pressure vessels, flanges, fittings, marine hardware, and chemical process plant components. It is also well suited for food and pharmaceutical equipment, where cleanliness and resistance to aggressive cleaning chemicals are paramount. The strength and corrosion resistance of the alloy at higher temperatures make it a good choice for exhaust manifolds, furnace components, and other high-temperature structural parts in harsh industrial conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
