George Metals, a prominent manufacturer and supplier located in Houston, USA, specializes in high-quality Stainless Steel 316L Bars and Rods. These products are well-known for their outstanding corrosion resistance, weldability, and durability. The 316L grade is a low-carbon variant of 316 stainless steel, specifically engineered to reduce carbide precipitation during welding, ensuring top-notch performance in environments rich in chlorides and acids. Manufactured according to ASTM A276 and A479 standards, these bars and rods come in a variety of sizes, finishes, and custom lengths. George Metals caters to industries such as chemical processing, marine, pharmaceuticals, and food processing, providing reliable 316L bars for essential structural and mechanical applications.
Stainless Steel 316L Bars and Rods are composed of 16–18% Chromium, 10–14% Nickel, 2–3% Molybdenum, and a maximum of 0.03% Carbon. This low carbon content enhances weldability and resistance to intergranular corrosion. With a tensile strength ranging from 485–620 MPa and excellent ductility, 316L is perfect for forming and machining. Its superior resistance to pitting and crevice corrosion makes it an ideal choice for applications exposed to chlorides. George Metals guarantees consistent metallurgical properties, precise tolerances, and a high-quality surface finish in every batch of 316L bars and rods, ensuring they meet demanding industrial performance standards.
| Specification | ASTM A276/ A479, ASME SA276/SA479 |
|---|---|
| Grade | Stainless Steel 316L (UNS S31603) |
| Flat bar size | 1/2” to 10” in thickness range of 2mm to 150mm |
| Square bar size | 18mm – 47mm (11/16″ to 1-3/4″) |
| Round bar size | Outside Diameter in the range of 4mm to 500mm |
| Hex Bar size | 18mm – 57mm (11/16″ to 2-3/4″) |
| Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular bar Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | 316L Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Processing | Bar cutting to 650mm |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Our 316L Stainless Steel Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.3 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16 – 18 | 2 – 3 | 10 – 14 | 0.10 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐032 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Stainless Steel 316L Bars and Rods find extensive use in industries that demand high corrosion resistance and exceptional weldability. In the chemical and petrochemical fields, they are utilized for piping, heat exchangers, valves, and process equipment that come into contact with harsh chemicals. The marine sector depends on 316L for shafts, fasteners, and components that face saltwater exposure. In the pharmaceutical and food industries, it’s favored for hygienic equipment due to its non-reactive and clean surface properties. Power plants and water treatment facilities also use 316L rods in critical assemblies. George Metals consistently delivers top-notch products to meet these rigorous demands.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
