George Metals, based in Houston, USA, is a well-known producer and exporter of Stainless Steel 316 Hex Bars and Rods, providing corrosion-resistant, high-strength products for industrial and commercial use. Renowned for precision machining and compliance with ASTM and ASME standards, George Metals offers 316 stainless steel products specifically manufactured according to customer requirements. Their hex bars and rods are extensively utilized in extreme conditions, proving high corrosion resistance, particularly in marine and chemical environments. With effective logistics, quality control, and technical services, George Metals is a trustworthy partner for stainless steel solutions in various industries.
Stainless Steel 316 Hex Bars and Rods consist of about 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, with the rest being iron. Addition of molybdenum gives improved resistance to corrosion, especially to chlorides and acidic conditions. Some mechanical properties are tensile strength of approximately 515 MPa, yield strength of 205 MPa, and elongation of approximately 40%. Bars have good toughness, weldability, and resistance at cryogenic temperatures. Stainless Steel 316 is not magnetic in the condition of annealed and has very good forming and machining properties, which make it suitable for precision-engineered components.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316 | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 0.03 max | 0.75 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | – | – | 515 Min | 205 Min | 40% Min |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
