Houston, USA-based George Metals is a leading manufacturer and supplier of Stainless Steel 310S square bars and rods with high-quality stainless steel solutions for corrosion-resistant and high-temperature applications. Dedicated to quality, reliability, and precision, George Metals supplies 310S square bars that are in line with international standards and meet varied industrial demands. They are internationally acclaimed for their performance in harsh environments. With cutting-edge manufacturing techniques coupled with superior customer service, George Metals has become a trusted business partner to clients operating in power plants, petrochemical plants, and heat treatment industries around the nation.
Stainless Steel 310S square bars/rods consist mainly of 25% chromium, 20% nickel, and low carbon content to promote weldability as well as reduce carbide precipitation. This makes 310S have excellent oxidation resistance and high temperature strength. Mechanical properties consist of a tensile strength of around 515 MPa, yield strength of 205 MPa, and adequate elongation and hardness. The structure is not lost during continuous service temperatures of up to 1150°C, indicating its suitability for high-temperature applications. Excellent ductility, creep resistance, as well as corrosion resistance in oxidizing and carburizing atmospheres, are also provided by the 310S type.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 310S | 0.08 max | 24.0 – 26.0 | 2.00 max | 19.0 – 22.0 | 0.045 max. | 0.03 max. | 1.50 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 310 | 8 | 1400 ℃ | 515 MPa | 205 | 40 – 50 | 160 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 310S | 1.4845 | S31008 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
