Varun Sheets and Plates is a highly acclaimed manufacturer and supplier of high-quality stainless steel materials in Dubai, UAE, which supplies accurately engineered Stainless Steel 310 Square Bars and Rods. These square bars, made to withstand high-temperature and corrosive processes, are well suited for heavy-duty industrial use. With emphasis on quality, reliability, and adherence to international standards, Varun supplies strong and robust products to industries like thermal processing, petrochemical, and power generation. Timely deliveries, technical know-how, and customer focus are hallmarks of the company, catering to customers in the UAE and the Middle East.
Square Bars/Rods of Stainless Steel 310 are produced from a high-temperature austenitic alloy with about 25% chromium and 20% nickel. This composition offers superior oxidation resistance and high temperature tensile strength. The material possesses a tensile strength of approximately 520 MPa and creep resistance. The product—Stainless Steel 310 Square Bar/Rod—is associated with sharp edges and uniformity in dimensions, making it ideal for precision machining and structure-related applications. It is in different sizes to satisfy particular industrial needs, with additional thermal stress and corrosion resistance.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 310 | 0.25 max | 24.0 – 26.0 | 2.00 max | 19.0 – 22.0 | 0.045 max. | 0.03 max. | 1.50 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 310 | 8 | 1400 ℃ | 515 MPa | 205 | 40 | 217 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 310 | 1.4841 | S31000 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
