George Metals is the leading supplier and manufacturer of Stainless Steel 304 Bars and Rods, offering a wide range of high-quality, durable, and corrosion-resistant products. Known for their versatility and strength, these bars and rods are ideal for various applications, including structural, automotive, and food processing industries. With a focus on precision and customer satisfaction, George Metals ensures timely delivery and competitive pricing, making them a trusted choice for businesses seeking reliable stainless steel solutions in Houston, USA.
Stainless Steel 304 Bars and Rods are composed of a blend of elements that ideally provide excellent corrosion resistance and strength. The chemical composition includes 18-20 percentage chromium, 8-10.5 percentage nickel, and a maximum 0.08 percentage carbon, besides 2 percentage manganese, 0.045 percentage phosphorus, and 0.03 percentage sulfur, with the materials being mostly iron, making up the balance. Mechanically, Stainless Steel 304 provides tensile strength of 515 MPa, its yield strength is 205 MPa with an elongation of 40% in 50 mm. It also has a hardness value of 92 HRB (Rockwell B); hence useful for a vast number of applications that require strength as well as resistance against corrosion.
| Specification | ASTM A479/ SA479 ASTM A276/ ASME SA276 |
|---|---|
| Grade | Stainless Steel 304 (UNS S30400) |
| Hex Bar size | 18 to 57mm (11/16″ – 2-3/4″) |
| Round bar size | OD 4mm to 500mm |
| Square bar size | 18mm to 47mm (11/16″- 1-3/4″) |
| Billet Size | 1/2″- 495mm Dia. |
| Rectangles Size | 33 x 30mm – 295 x 1066mm |
| Bright Bar | OD 4mm to 100mm |
| Tolerance | K12 H12, K10, H9, H11, H8, H13K9, H10, K11, or as per need |
| Flat bar size | 1/2” to 10” in thickness of 2 to 150mm |
| Angle bar size | 3*20*20~12*100*100 |
| Finish | centreless ground, Cold (bright) drawn, hot rolled, peeled, smooth turned, hot rolled annealed, slit rolled edge, Bright, Rough Turned, Grinding, Polish & Black |
| Form | Flat Bar, Hollow, Round, Square, Triangle, Rectangle, Half Round Bar, Rod, T-Bar, Precision Ground Bar, Hex (A/F), Blocks, Channel Bar, Threaded, Round Rod, Billet, Profiles, I/H Bar, Ingot, Rings, Forging etc. |
| Technique | 440C Stainless Steel Hot Rolled, Cold Drawn, Rod, Forged Round Bar, Cold Rolled |
| Condition | annealed, Hardened & tempered |
| Section | 3.0 -12.0 mm thickness, 80 x 40 to 150 x 75mm section |
| Channel Bar | 5.0 – 6.0mm thickness |
| Surface | Bright, Cold Drawn, Hot Rolled Pickled, Sand Blasting Finished, Polished, Hairline |
| Hollow Bar | 32mm OD x 16mm ID – 250mm OD x 200mm ID |
| Grade | Mn | C | Si | S | P | Cr | Ni | Mo | N |
| SS 304 | 2 maximum | 0.08 maximum | 0.75 maximum | 0.030 maximum | 0.040 maximum | 18 – 20 | 8 – 11 | – | – |
| Density | Elongation | Tensile Strength | Melting Point | (0.2%Offset) Yield Strength |
| 8.0 g/cm3 | 35 % | MPa – 515 , Psi – 75000 | 1400 °C (2550 °F) | MPa – 205, Psi – 30000 |
|
Type |
SIZES (Inches) |
ISO Tolerance |
SIZES (mm) |
|---|---|---|---|
|
Peeled and Polished |
1.50″ to 6.00″ |
h11-DIN 1013 |
40.00 to 150.00 |
|
Cold Drawn and Ground |
5/6″ to 2.50″ |
h9-h8-h11-h10 |
10.00 to 75.00 |
|
Cold Drawn and Polish |
1/8″ to 3.00″ |
h9-h8-h11-h10 |
3.00 to 75.00 |
|
Peeled and Ground |
3/4″ to 2.00″ |
h10-h9-h11 |
20.00 to 50.00 |
|
STANDARD |
UNS |
WERKSTOFF NR. |
BS |
JIS |
AFNOR |
GOST |
EN |
|
SS 304 |
S30400 |
1.4301 |
304S31 |
SUS 304 |
Z7CN18‐09 |
08Х18Н10 |
X5CrNi18-10 |
Stainless Steel 304 Bars and Rods offer excellent corrosion resistance, high tensile strength, and good machinability. They are also highly resistant to oxidation and can withstand various industrial and environmental conditions, making them suitable for a wide range of applications.
Stainless Steel 304 Bars and Rods are widely used in industries such as food processing, automotive, chemical, pharmaceutical, and construction. They are used for manufacturing parts like shafts, fasteners, pipes, and structural components due to their durability and corrosion resistance.
Yes, Stainless Steel 304 Bars and Rods perform well in high-temperature environments, with the ability to withstand temperatures up to 870°C (1600°F) in intermittent service. This makes them suitable for applications in heat exchangers, ovens, and other high-heat environments.
Stainless Steel 304 Bars and Rods in a variety of applications due to their excellent strength, corrosion resistance, and durability. They are ideal for manufacturing components like shafts, bolts, and fasteners, which I rely on in many projects. I also use them in the food processing industry, for kitchen appliances, and in pharmaceutical manufacturing due to their resistance to corrosion. In addition, I depend on Stainless Steel 304 for structural applications such as railings, pipes, and fittings. It’s also my go-to material for automotive parts, chemical processing equipment, and heat exchangers, making it incredibly versatile for my needs.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
George Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Houston, USA
