Varun Sheets and Plates is a prominent distributor and manufacturer of high-performance stainless steel items in Dubai, UAE, providing superior Stainless Steel 17-4 PH Hex Bars and Rods. Famous for their high strength, hardness, and corrosion resistance, these bars are suitable for challenging engineering and aerospace applications. Precision-engineered and manufactured to international standards, Varun provides consistent quality, superior mechanical properties, and quick turnaround times. Supplying industries including aerospace, petrochemical, defense, and marine industries, the company is known throughout the UAE and Middle East for technical superiority and trustworthy supply solutions.
Hex Bar/Rod Stainless Steel 17-4 PH is a precipitation-hardening martensitic stainless steel alloy that contains around 17% chromium, 4% nickel, 3–5% copper, and traces of niobium. It has great mechanical properties, with a tensile strength of up to 1100 MPa following heat treatment, as well as good corrosion resistance. The item—Stainless Steel 17-4 PH Hex Bar/Rod—is in a range of sizes and hardness conditions (e.g., H900, H1025), and is well suited for precision-machined components that have both high strength and low corrosion resistance.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 17-4 PH | 0.07 max | 0.15-0.45 max | 15.00-17.50 max | 3.00-5.00 max | Bal | 1.0 | 3.0-5.0 | 0.40 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 17-4 PH | 170000 psi | 140000 psi | 6% | 38 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-4 PH | 1.4542 | S17400 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
