Varun Sheets and Plates is a prominent manufacturer and supplier of high-performance stainless steel components in Dubai, UAE, providing precision-fabricated Stainless Steel 15-5 PH Hex Bars and Rods. The bars are renowned for their elevated strength, superior toughness, and excellent corrosion resistance, making them suitable for aerospace, chemical, and marine sectors. Made with state-of-the-art technologies and as per international standards, Varun guarantees stable quality, stringent tolerances, and quick delivery. The organization is reliably followed in the UAE and Middle East for providing stainless steel materials that fulfill the toughest industrial specifications.
Stainless Steel 15-5 PH Hex Bar/Rod is a martensitic precipitation-hardening stainless steel alloy containing around 15% chromium and 5% nickel. It also includes minor content of copper, which gives it the ability to age-harden. When heat-treated, it provides tensile strength as high as 1100 MPa, has good ductility, and corrosion resistance. The final product—Stainless Steel 15-5 PH Hex Bar/Rod—is supplied in different conditions of hardness (H900, H1025, etc.) and sizes with machinability and stability of dimensions, and is used for applications that demand precision and strength.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 15-5 PH | 0.07 max | 0.15-0.45 max | 14.0-15.0 max | 2.5-4.5 max | Bal | 1.0 | 3.5-5.5 | 0.04 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 15-5 PH | 161,000 | 140,000 | 7.6% | C35 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 15-5PH | 1.4545 | S15500 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
