George Metals, a top-notch manufacturer and supplier located in Houston, USA, focuses on crafting high-performance Nickel Alloy Bars and Rods designed to thrive in extreme industrial settings. These bars and rods are celebrated for their remarkable resistance to corrosion, heat, and pressure, making them perfect for the toughest applications. With a variety of grades available, including Inconel, Monel, Hastelloy, and Nickel 200/201, George Metals produces all their products in line with ASTM, ASME, and international standards. Known for their exceptional dimensional accuracy, surface finish, and mechanical reliability, George Metals provides nickel alloy bars and rods that industries like aerospace, petrochemical, power generation, and marine engineering can depend on.
Nickel Alloy Bars and Rods are primarily made up of Nickel (ranging from 60% to 99% depending on the grade), with alloying elements like Chromium, Molybdenum, Iron, Copper, and Cobalt that boost their corrosion resistance and high-temperature strength. These alloys showcase tensile strengths between 500–900 MPa and provide excellent creep resistance, thermal stability, and weldability. George Metals guarantees a uniform grain structure, rigorous quality control, and precise dimensional tolerances, ensuring their nickel alloy bars are perfect for machining, forging, and fabricating in high-stress environments that face harsh chemical and thermal conditions.
Nickel Round Bar Specification : ASTM B160, ASME SB160
Dimension Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 14mm-300mm
Thickness : 50 mm to 6000 mm Long
Length : 1 To 6 Meters, Custom Cut Length
Form : Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | UNS | WNR. | JIS | EN |
|---|---|---|---|---|
| Nickel 200 | N02200 | 2.4066 | NW 2200 | Ni 99.2 |
| Nickel 201 | N02201 | 2.4068 | NW 2201 | LC-Ni 99 |
Nickel Alloy Bars and Rods play a crucial role in industries that require high resistance to corrosion, heat, and mechanical fatigue. In aerospace, they’re utilized for turbine blades, structural components, and exhaust systems. The chemical and petrochemical sectors depend on them for reactors, columns, and acid-handling equipment. Power plants use nickel alloys in heat exchangers, steam systems, and components for nuclear reactors. The marine and offshore industries rely on them for pump shafts, valves, and fasteners due to their excellent resistance to seawater. George Metals provides precision-cut nickel alloy bars that meet the demanding needs of these sectors.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
