George Metals, based in Houston, USA, is a reliable manufacturer and supplier known for its top-notch Nickel Alloy 201 Bars and Rods. These products are crafted to offer exceptional corrosion resistance, thermal conductivity, and dependable performance even in tough conditions. Adhering to strict ASTM, ASME, and international standards, these nickel products are made with low carbon content to avoid embrittlement at high temperatures. With various diameters, lengths, and finishes available, Nickel Alloy 201 Bars and Rods are easy to machine and form. Industries like chemical processing, electronics, food manufacturing, and marine trust George Metals for consistent quality, reliable supply, and expert knowledge in high-purity nickel alloys.
Nickel Alloy 201 Bars and Rods consist of about 99.6% pure nickel, with a maximum carbon content of 0.02%, which helps minimize the risk of graphitization at temperatures above 315 °C (600 °F). They boast a tensile strength of around 380 MPa and a yield strength close to 105 MPa, along with impressive ductility and toughness. Nickel 201 excels in resisting caustic alkalis, neutral and alkaline salt solutions, and reducing chemicals. It also provides excellent thermal and electrical conductivity while maintaining mechanical stability across a wide temperature range, making it perfect for corrosive and high-purity process applications.
| Grade | Nickel 201 |
|---|---|
| Specification | UNS N02201, ASME SB160/ASTM B160 |
| Round bar size | Dia: 3mm~800mm |
| Hollow Bar | 32 OD x 16 ID to 250 OD x 200 ID |
| Square bar size | 4mm to 100mm |
| Hex Bar size | 2mm to 100mm A/F |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40 to 150 x 75mm section; 5 to 6mm thickness |
| Flat bar size | Thickness: 2mm to 100mm |
| Width: 10mm to 500mm | |
| Hollow Bar | 32mm Outside Diameter x 16mm Inside Diameter to 250mm Outside Diameter x 200mm Inside Diameter) |
| Angle bar size | 3*20*20~12*100*100 |
| Form | Rings, Hollow, Flat Bar, Rectangle, Triangle, Square,Rod, Half Round Bar, T-Bar, Hex (A/F), Precision Ground Bar, Round, Channel Bar, Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Tolerance | H8, K12, H10, H11, K10, H9, K11, K9, H12, H13, or custom |
| Technique | Forged Round Bar, Rod, Hot Rolled, Cold Drawn, Cold Rolled, |
| Condition | annealed, Hardened and tempered |
| Surface | Polished, Cold Drawn, Hot Rolled Pickled, Sand Blasting Finished, Bright, Hairline |
|
Grade |
Fe |
Si |
C |
S |
Ni |
Mn |
Mg |
Cu |
Ti |
|---|---|---|---|---|---|---|---|---|---|
|
Nickel 201 |
0.4 max |
0.2 max |
0.02 max |
0.01 max |
99.0 min |
0.35 max |
0.15 max |
0.25 max |
0.1 max |
|
Density |
Elongation |
Tensile Strength |
Melting Point |
Yield Strength (0.2%Offset) |
|---|---|---|---|---|
|
8.9 g/cm3 |
45 % |
Psi – 67000 , MPa – 462 |
1446 °C (2635 °F) |
Psi – 21500 , MPa – 148 |
|
STANDARD |
UNS |
WERKSTOFF NR. |
AFNOR |
GOST |
BS |
JIS |
EN |
|---|---|---|---|---|---|---|---|
|
Nickel 201 |
N02201 |
2.4068 |
– |
НП-2 |
NA 12 |
NW 2201 |
NLC-Ni 99 |
Type | SIZES (Inches) | ISO Tolerance | SIZES (mm) |
|---|---|---|---|
Peeled and Polished | 1.50″ to 6.00″ | h11-DIN 1013 | 40.00 to 150.00 |
Cold Drawn and Ground | 5/6″ to 2.50″ | h9-h8-h11-h10 | 10.00 to 75.00 |
Cold Drawn and Polish | 1/8″ to 3.00″ | h9-h8-h11-h10 | 3.00 to 75.00 |
Peeled and Ground | 3/4″ to 2.00″ | h10-h9-h11 | 20.00 to 50.00 |
Cut to size on request (tolerance +2/-0 mm).
50.0 | 6.0 |
45.0 | 5.0 |
60.0 | 8.0 |
55.0 | 7.0 |
70.0 | 10.0 |
65.0 | 9.0 |
75.0 | 12.0 |
90.0 | 20.0 |
80.0 | 16.0 |
100.0 | 25.0 |
160.0 | 35.0 |
130.0 | 30.0 |
200.0 | 40.0 |
Nickel Alloy 201 Bars and Rods are extensively utilized in situations that demand outstanding corrosion resistance and high purity. In the chemical processing sector, they are essential for producing caustic soda and for use in reactors and evaporators that handle caustic and acidic substances. Electronics manufacturers choose them for battery components, anodes, and electrical contacts because of their excellent conductivity. In food and beverage processing, Nickel 201 is favored for its clean, non-contaminating surfaces. Additionally, marine environments benefit from its resistance to seawater and brine, while other applications include heat exchangers and various industrial equipment.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
