Houston, USA-based Brian Fasteners is a leading producer and distributor of Inconel 625 forgings, designed for enhanced strength and corrosion resistance in harsh conditions. The forgings are manufactured with premium nickel-based alloy Inconel 625 and forged to precise requirements for aerospace, marine, and chemical applications. Using high-level production technology and quality control, Brian Fasteners produces high-performance forged items such as flanges, shafts, rings, and blocks. Quick turnaround, bespoke dimensions, and complete traceability are provided by the company to facilitate critical applications requiring extended service life and dependability in hostile environments.
Inconel 625 forgings consist of about 58% Ni, 20–23% Cr, 8–10% Mo, 3.15–4.15% Nb+Ta, with trace Fe, Ti, and Al. They have tensile strength of up to 930 MPa, yield strength of about 450–620 MPa, and elongation of 25–35%. The alloy retains outstanding mechanical properties from cryogenic to 980°C. Brian Fasteners’ Inconel 625 forgings offer superior resistance to pitting by chloride, oxidation, and stress-corrosion cracking. These attributes make them especially suitable for application in high-temperature and high-pressure environments where long-term structural integrity and durability are critical.
Specifications ASTM B564 / ASME SB564, AMS 5666
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | C | Mn | Si | S | Al | Ti | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 0.40 max | 0.40 max | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa -930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Alloy 625 | N06625 | 2.4856 | NC22DNB4M | NiCr22Mo9Nb | NCF 625 | NA 21 | ХН75МБТЮ | ЭИ602 |
Temperature control during forging of Inconel 625 ensures optimal material properties, preventing brittleness and maintaining its strength and ductility. Proper temperature management also enhances uniformity, reducing defects and improving overall quality.
Inconel 625 Forgings are expensive due to the high cost of raw materials and complex manufacturing processes. Additionally, their workability can be challenging at certain temperatures, requiring specialized equipment and techniques.
To determine if Inconel 625 Forgings meet your needs, compare their material properties with your application requirements and consult with suppliers for tailored solutions.
Brian Fasteners’ forgings of Inconel 625 find extensive application in aerospace exhaust systems, offshore structures, marine technology, and chemical plant processing. Uses are in turbine casings, valve parts, seals, flanges, and heat exchanger components. They have excellent corrosion resistance for use with saltwater, sour gas, and oxidizing acids. In the nuclear and power generation industries, reactor core and structural supports utilize them. These forgings are particularly suitable for applications with high strength and superior weldability under harsh conditions. Brian Fasteners ensures each forging is carefully crafted to exacting industry standards and aid in critical operations.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
