Houston-based George Metals is a leading producer and supplier of Inconel 617 Forgings with high-strength, corrosion-resistant components suited for extreme-temperature and chemically aggressive environments. Produced to ASTM B564 and ASME SB-564 specifications, these forgings are precision-made to suit the stringent requirements of aerospace, power generation, and petrochemical sectors. George Metals offers forging solutions custom-tailored, with dimensional accuracy, high metallurgical integrity, and full traceability. Their dedication to quality, quick lead times, and technical support has them as the go-to supplier of Inconel 617 forgings for high-performance critical applications.
Inconel 617 Forgings are produced from a solid solution-strengthened nickel-chromium-cobalt-molybdenum alloy with about 44.5% Ni, 20–24% Cr, 10–15% Co, and 8–10% Mo content, plus added aluminum and trace amounts of titanium to enhance oxidation resistance and strength. This composition has very good mechanical properties with tensile strength of approximately 770 MPa, yield strength of approximately 320 MPa, and elongation of 50% in solution-annealed condition. Inconel 617 exhibits high creep-rupture strength at temperatures above 980°C and possesses outstanding resistance to oxidation, carburization, and a broad spectrum of corrosive environments and hence finds application in high-stress, high-temperature conditions.
Specifications ASTM B564 / ASME SB 564, AMS 5887
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| STANDARD | UNS | WNR. |
| Alloy 617 | N06617 | 2.4663 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
