Brian Fasteners produces Incoloy 925 Bars and Rods in Houston, USA. This nickel-iron-chromium alloy with molybdenum, copper, and titanium offers high mechanical strength and outstanding resistance to chlorides, H₂S, wet CO₂, and oxidation. Manufactured through vacuum melting and careful processing, 925 bars maintain dimensional accuracy and metallurgical quality. Ideal for oil and gas, marine, and chemical processing environments, Brian Fasteners delivers custom sizes, fast delivery, and full material certification, ensuring performance and corrosion protection in tough industrial applications.
Incoloy 925 comprises about 42% nickel, 21 to 23% chromium, 29 to 31% iron, 2.5 to 3.2% molybdenum, around 1.5% copper, and 1% titanium. It offers tensile strength of about 600 to 800 MPa, yield strength of around 300 to 500 MPa, and elongation of 25 to 40%. Maintaining strength up to 800 °C, it resists chloride pitting, stress corrosion cracking, and wet H₂S attack, with a stable microstructure under thermal cycling.
| Standards | ASTM B805, ASME SB 805 |
|---|---|
| Specifications | DIN, EN, ASTM, JIS, ASME, BS, AISI |
| 925 Incoloy Round Bars size | Diameter: 3-~800mm |
| Incoloy 925 Flat Bars size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Incoloy 925 Angle Bars size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Incoloy 925 Channel Bars | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Alloy 925 Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Incoloy 925 Billet Size | 1/2 to 495mm Diameter |
| Incoloy 925 Rectangle Bar Size | 33 x 30mm to 295 x 1066mm |
| Incoloy 925 Hex Bar size | 2-100mm A/F |
| Incoloy 925 Hollow Bars | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Diameter | 20mm, 30mm, 50mm, 80mm, 100mm, 150mm, 200mm, 500mm |
| Length | 1m-12m or as required |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | hot rolled annealed, peeled, Bright, hot-worked and cold-worked rod and bar, centreless ground, Centreless Ground and Black, Polish, Cold Rolled (CR), hot rolled ( R), smooth turned, Cold (bright) drawn, Grinding, slit rolled edge, Rough Turned. |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Cold Drawn, Hot Rolled, Forged Round Bars, Cold Rolled, Rod |
| Processing | Bars cutting to 650mm |
| Form | Rod, Round, Channel Bars, T-Bars, Flat Bars, Precision Ground Bars, Blocks, Square, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bars, Ingot, Billet, I/H Bars, Forging etc. |
| Grade | Ni | Cr | Fe | Si | Mo | Cu | Mn | C | S | Al |
| Incoloy 925 | 42 – 46 | 19.55 – 22.5 | 22 min | 0.5 max | 2.5 – 3.5 | 1.5 – 3.0 | 1.0 max | 0.03 max | 0.03 max | 0.1 – 0.5 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.14 g/cm3 | 1343°C | 650 | 300 | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Incoloy 925 | – | N09925 |
Yes, Incoloy 925 rods are highly corrosion-resistant, particularly in aggressive environments such as acidic and chloride-containing media. Their composition includes nickel, iron, and chromium, enhancing their resistance to corrosion, pitting, and stress corrosion cracking.
Yes, Incoloy 925 bars can be customized in size and length to meet specific requirements. They are available in various dimensions and can be tailored for different industrial applications.
Incoloy 925 bars perform exceptionally well in high-temperature environments, maintaining strength and stability. Their high nickel and chromium content provides excellent resistance to oxidation and carburization at elevated temperatures.
925 bars are utilized for oilfield tubing, chemical processing equipment, marine heat exchangers, flue gas desulfurization ducts, and pressure vessels. Their resistance to chlorides and H₂S makes them suitable for sour-gas environments. Brian Fasteners provides precise Incoloy 925 bars designed for durability in energy, petrochemical, and marine sectors that require corrosion-resistant alloys.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
