George Metals, based in Houston, USA, stands out as a top manufacturer and supplier of Incoloy 330 Bars and Rods. These products are celebrated for their remarkable resistance to oxidation and carburization, along with impressive strength at high temperatures. Incoloy 330 (UNS N08330) is a specialized nickel-iron-chromium alloy crafted for high-temperature furnace applications and thermal processing systems. George Metals provides these bars and rods in a variety of sizes, finishes, and tolerances, all adhering to international standards like ASTM B511/B535. Their outstanding durability under thermal cycling and mechanical stress makes them perfect for the chemical, heat treating, and petrochemical sectors.
Incoloy 330 Bars and Rods from George Metals are made up of about 35–37% nickel and 17–20% chromium, with balanced amounts of iron, silicon, and manganese. This alloy boasts a tensile strength of around 600 MPa, a yield strength of about 250 MPa, and impressive elongation (≥30%), even at temperatures over 1150°C (2100°F). It effectively resists scaling, oxidation, and carburization in high-temperature environments. The bars come in either an annealed or cold-drawn state, ensuring they are easy to work with and weld while maintaining their shape and performance in extreme conditions.
| Grade | Incoloy 330 – UNS N08330 |
|---|---|
| Specification | ASTM B511 UNS N08330, AMS 5716, ASTM B511, ASME SB511 |
| Round bar size | Diameter: 3-~330mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Round Bar Standard Dimensions | Diameter / Height: |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | Incoloy 330 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | Incoloy 330 Rod,Channel Bar, Forging, Precision Ground Bar, Flat Bar, Round, Rod, T-Bar, Square, Blocks, Round Rod, Rings, Hollow, Threaded, Half Round Bar, Profiles, Triangle, Rectangle, Hex (A/F), Billet, Ingot, I/H Bar etc. |
| Our stockyad location for fast delivery across India | Shivamogga, Agra, Ahmedabad, Mumbai, Dhanbad, Thiruvananthapuram, Bengaluru, Tiruchirappalli, Pune, Noida, Tirunelveli, Bhubaneswar, Chennai, Coimbatore, Pimpri-Chinchwad, Hyderabad, Navi Mumbai |
| Our Incoloy 330 Round bar conforms to NACE MR0175/ISO 15156 | |
|
Element |
Average Nominal % |
|---|---|
|
Chromium |
18.00 – 22.00 |
|
Nickel |
34.00 37.00 |
|
Carbon |
0.08 Max |
|
Silicon |
1.00 – 1.50 |
|
Manganese |
2.00 Max |
|
Phosphorus |
0.03 Max |
|
Sulfur |
0.03 Max |
|
Copper |
1.00 Max |
|
Iron |
Balance |
|
Tensile Strength – ksi (min.) |
0.2% Offset Yield Strength – ksi (min.) |
Elongation in 2 inches – % (min.) |
Hardness – Rockwell B |
|---|---|---|---|
|
70 |
30 |
30 |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Incoloy 330 | 1.4886 | N08330 |
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
George Metals’ Incoloy 330 Bars and Rods find extensive use in high-temperature industrial settings, such as heat exchangers, furnace components, radiant tubes, retorts, muffles, and cracking trays. Their exceptional ability to withstand thermal shock, carburization, and various atmospheres makes them ideal for petrochemical refining, metallurgy, thermal processing, and industrial heating equipment. In the chemical sector, they are utilized in ammonia reformers, gas turbine parts, and process piping. George Metals guarantees precision machining and consistent metallurgical properties, delivering Incoloy 330 bars that meet the highest standards.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
