At George Metals, based in Houston, USA, we pride ourselves on being a reliable manufacturer and supplier of Hastelloy C276 Forgings. These forgings are celebrated for their remarkable resistance to corrosive environments and their mechanical dependability. Hastelloy C276 is a unique alloy made of nickel, molybdenum, chromium, and a touch of tungsten, crafted to withstand harsh chemical conditions like strong oxidizers, acids, and chlorides. We offer a diverse selection of precision-forged components, including rings, blocks, shafts, discs, and custom shapes, all produced to meet ASTM B564 and other international standards. Our forgings find their place in various industries, such as chemical processing, marine, pollution control, pulp & paper, and pharmaceuticals, thanks to their long-lasting corrosion resistance.
Hastelloy C276 Forgings from George Metals are composed of nickel (the balance), 15–17% molybdenum, 14.5–16.5% chromium, 4–7% iron, and 3–4.5% tungsten, along with trace elements of cobalt, manganese, and vanadium. This specific blend grants exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking, even in the most challenging chemical environments. Our forged C276 boasts a tensile strength of around 760 MPa, a yield strength of about 283 MPa, and impressive ductility. Typically, these forgings undergo solution heat treatment to enhance their corrosion resistance and mechanical strength, making them perfect for demanding service conditions across a variety of industrial applications.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Hastelloy C276 Forging UNS (N10276), DIN (2.4819)
ISO 9725
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy C276 | Balance | 0.01 max | 15–17 | 1.0 max | 0.08 max | 4–7 | 0.04 max | 0.03 max | 2.5 max | 14.5–16.5 | 3–4.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
George Metals’ Hastelloy C276 Forgings are extensively utilized in sectors that require outstanding corrosion resistance in extreme conditions. You’ll find them in chemical reactors, heat exchangers, pumps, agitators, pressure vessels, and valve components across chemical processing, waste treatment, offshore oil & gas, and marine settings. These forgings excel in systems that deal with sulfuric acid, hydrochloric acid, chlorine gas, and organic solvents. Their ability to resist both oxidizing and reducing agents makes them a top choice for challenging environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
George Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Houston, USA
