George Metals, located in Houston, USA, stands out as a top-notch manufacturer and supplier of high-quality Copper Round Bars. With a solid reputation for excellence, this company provides premium copper products tailored to meet the varied needs of industries like electrical, construction, and automotive. These bars are celebrated for their remarkable conductivity, malleability, and durability, crafted to perfection while adhering to international standards. George Metals takes pride in offering customized solutions, ensuring that their products deliver superior performance and reliability across all applications.
Copper Round Bars are made up of pure copper (99.9%), which is renowned for its outstanding thermal and electrical conductivity. These bars boast a tensile strength ranging from 200-250 MPa and a yield strength of 70-100 MPa, depending on the specific alloy grade. Thanks to their excellent malleability and ductility, Copper Round Bars are easy to machine, weld, and fabricate. Their impressive resistance to corrosion guarantees long-lasting durability, making them ideal for even the toughest environments.
| Grade | Copper – UNS C12200 |
|---|---|
| Specification | ASTM B62 UNS C12200 |
| Standard | ASTM, ASME, API, GB, AISI, DIN, EN, SUS, UNS, ASTM B62 / ASME SB62 |
| Copper Round bar size | Diameter: 3mm~800mm |
| Copper Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Copper Square bar size | 4mm*4mm~100mm*100mm |
| Copper Flat bar size | Thickness: 2mm~100mm |
| Width: 10mm~500mm | |
| Copper Hex Bar size | 2mm~100mm |
| Copper Billet Size | 1/2″ to 495mm Diameter |
| Copper Rectangles Size | 33mm x 30mm to 295mm x 1066mm |
| LENGTHS | 12 RANDOM LENGTHS AND LONG BARS:15 20 RANDOM LENGTHS |
| Finish | Bright, Polish, Bright, Rough Turned, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline |
| Condition | Cold Drawnd Pulished Cold Drawn Centreless Ground & Polished, Annealed round bar |
| Technique | Copper Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rod |
| Form | Round, Rod, Precision Ground Bar, Square, Round Rod, Hollow, Hex (A/F), Triangle, Rectangle, Threaded, T-Bar, Half Round Bar, Flat Bar, Rings, Blocks, Billet, Ingot, I/H Bar, Angle, Channel Bar, Profiles, Forging Etc. |
| Our Copper round bar conforms to NACE MR0175/ISO 15156 | |
|
Standard |
Copper NO. |
Chemical Composition |
|
|
CU% |
P% |
||
|
ASTM
B280/62 |
C12200 |
>99.9 |
0.015 to 0.040 |
|
Mechanical Properties |
|||
|
Temper |
Tensile strength (Mpa) |
Elongation (%) |
Average Grain Size (mm) |
|
>60 |
>205 |
>40 |
>0.040 |
|
>50 |
>245 |
||
|
BS EN NUMBER |
TITLE |
NEAREST OLD BS EQUIVALENT |
|---|---|---|
|
Unwrought Products |
||
|
1976 |
Cast unwrought copper products |
6017 |
|
1977 |
Copper drawing stock (wire rod) |
6926 |
|
1978 |
Copper cathods |
6017 |
|
1981 |
Master Alloys |
– |
|
1982 |
Ingots and castings |
1400 |
|
Copper Rod / Bar, Wire, Profiles |
||
|
12163 |
Rod for general purposes |
2874 |
|
12164 |
Rod for free machining purposes |
2874 |
|
12165 |
Wrought and unwrought forging stock |
2872 |
|
12167 |
Profiles and rectangular bar for general purposes |
2874 |
|
12168 |
Hollow rod for free machining purposes |
– |
|
13347 |
Rod and wire for welding and braze welding |
1453, 1845, 2901 |
|
Copper Electrical Purposes |
||
|
13601 |
Copper rod, bar and wire general electrical purposes |
1433, 1432, 4109 |
|
13605 |
Copper profiles for electrical purposes |
|
Copper Ann- Round * CG – Centerless Ground | 3/16 CG Copper Bar 1/4 CG Copper Bar 5/16 CG Copper Bar 3/8 CG Copper Bar 1/2 CG Copper Bar 5/8 CG Copper Bar 3/4 CG Copper Bar 13/16 CG Copper Bar 7/8 CG Copper Bar 1 CG Copper Bar 1-1/8 CG Copper Bar 1-1/4 CG Copper Bar 1-3/8 CG Copper Bar 1-1/2 CG Copper Bar 1-3/4 CG Copper Bar | 2 CG Copper Bar 2-1/4 CG Copper Bar 2-1/2 CG Copper Bar 2-3/4 CG Copper Bar 3 CG Copper Bar 3-1/4 CG Copper Bar 3-1/2 CG Copper Bar 4 HR RT Copper Bar 4-1/2 HR RT Copper Bar 5 HR RT Copper Bar 6 HR RT Copper Bar 7 HR RT Copper Bar 8 HR RT Copper Bar 9 HR RT Copper Bar 10 HR RT Copper Bar |
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8” – 3.00” | h8-h9-h10-h11, ASTM B62 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6” – 2.50” | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50” – 6.00” | h11, ASTMA-484 h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00” | h9-h10-h11, ASTM B62 |
|
Round Bar |
||||||||
|---|---|---|---|---|---|---|---|---|
|
Size |
Kgs / Foot |
Kgs / Mtr |
Size |
Kgs / Foot |
Kgs / Mtr |
Size |
Kgs / Foot |
Kgs / Mtr |
|
3mm |
0.017 |
0.055 |
20mm |
0.753 |
2.470 |
3″ |
10.900 |
35.762 |
|
1/8″ |
0.019 |
0.062 |
22mm |
0.908 |
2.979 |
3-1/4″ |
12.800 |
41.996 |
|
5/32″ |
0.029 |
0.095 |
7/8″ |
0.926 |
3.038 |
3-1/2″ |
14.850 |
48.772 |
|
4mm |
0.030 |
0.098 |
24mm |
1.080 |
3.543 |
3-3/4″ |
17.001 |
55.780 |
|
3/16″ |
0.043 |
0.141 |
25mm |
1.180 |
3.871 |
4″ |
19.306 |
63.340 |
|
5mm |
0.047 |
0.154 |
1″ |
1.210 |
3.970 |
4-1/4″ |
21.908 |
72.249 |
|
7/32″ |
0.058 |
0.190 |
26mm |
1.271 |
4.170 |
4-1/2″ |
24.4487 |
80.340 |
|
6mm |
0.068 |
0.223 |
27mm |
1.368 |
4.490 |
4-3/4″ |
27.366 |
90.249 |
|
1/4″ |
0.076 |
0.249 |
1-1/8″ |
1.534 |
5.033 |
5″ |
30.461 |
99.940 |
|
7mm |
0.091 |
0.298 |
30mm |
1.691 |
5.548 |
5-1/2″ |
36.690 |
121.000 |
|
5/16″ |
0.118 |
0.387 |
1-1/4″ |
1.924 |
6.349 |
6″ |
43.860 |
143.900 |
|
8mm |
0.120 |
0.398 |
32mm |
1.894 |
6.314 |
6-1/2″ |
51.093 |
167.630 |
|
9mm |
0.152 |
0.498 |
1-3/8″ |
2.303 |
7.550 |
7″ |
59.432 |
196.000 |
|
3/8″ |
0.170 |
0.557 |
35mm |
2.390 |
7.553 |
7-1/2″ |
68.226 |
225.000 |
|
10mm |
0.189 |
0.620 |
36mm |
2.438 |
7.999 |
8″ |
77.586 |
254.55 |
|
11mm |
0.228 |
0.748 |
38mm |
2.792 |
8.903 |
10″ |
121.048 |
397.140 |
|
7/16″ |
0.232 |
0.761 |
1-1/2″ |
2.715 |
8.951 |
|||
|
12mm |
0.271 |
0.889 |
40mm |
3.009 |
9.872 |
|||
|
1/2″ |
0.303 |
0.994 |
1-5/8″ |
3.200 |
10.449 |
|||
|
13mm |
0.318 |
1.043 |
1-3/4″ |
3.712 |
12.179 |
|||
|
14mm |
0.368 |
1.207 |
45mm |
3.807 |
12.555 |
|||
|
9/16″ |
0.383 |
1.256 |
1-7/8″ |
4.260 |
13.977 |
|||
|
15mm |
0.424 |
1.391 |
48mm |
4.330 |
14.205 |
|||
|
5/8″ |
0.473 |
1.551 |
50mm |
4.698 |
15.414 |
|||
|
16mm |
0.481 |
1.578 |
2″ |
4.848 |
15.906 |
|||
|
17mm |
0.543 |
1.791 |
2-1/8″ |
5.475 |
17.963 |
|||
|
11/16″ |
0.573 |
1.880 |
2-1/4″ |
6.135 |
20.128 |
|||
|
18mm |
0.610 |
2.001 |
60mm |
6.768 |
22.205 |
|||
|
3/4″ |
0.682 |
2.237 |
2-3/8″ |
6.838 |
22.435 |
|||
|
2-1/2″ |
7.576 |
24.856 |
||||||
|
2-5/8″ |
8.354 |
27.409 |
||||||
|
2-3/4″ |
9.169 |
30.083 |
||||||
Copper Round Bars are widely utilized across various industries due to their exceptional electrical and thermal conductivity. They play a crucial role in electrical wiring, bus bars, connectors, and switchgear components. In plumbing and construction, they are trusted materials for pipelines and structural elements. The automotive sector employs them for radiators and heat exchangers, while their antimicrobial properties make them perfect for medical and food-grade applications. Plus, their visual appeal means they’re also featured in artistic and architectural projects.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
