George Metals, located in Houston, USA, stands out as a top manufacturer and supplier of high-quality Copper Nickel Rectangular Bars. With a strong focus on excellence and customer satisfaction, the company provides bars that adhere to international standards for performance and reliability. Renowned for their corrosion resistance and durability, these bars are made from premium-grade raw materials and utilize advanced manufacturing techniques. George Metals serves a variety of industries, including marine, power generation, and petrochemical sectors, ensuring timely delivery and consistent product quality for every order, which has earned them a solid reputation in the copper-nickel alloy market.
Copper Nickel Rectangular Bars are mainly made up of copper and nickel, usually in a 90/10 or 70/30 ratio, with small amounts of iron and manganese added to boost corrosion resistance and strength. These bars boast impressive mechanical properties, such as good tensile strength, moderate yield strength, and high impact resistance, even in low temperatures. They also show excellent ductility and toughness, making them ideal for fabrication and forming. The alloy’s ability to resist stress corrosion cracking and erosion further enhances its dependable performance in challenging marine and industrial environments.
| Standard | ASTM B111, ASME SB111 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Mn | Cu | Pb | Fe | Ni | Zn |
|---|---|---|---|---|---|---|
| 90/10 | 1.0 max | 88.6 min | 0.5 max | 1.8 max | 9-11 max | 1 max |
| 70/30 | 1 max | 65.0 min | 0.5 max | 0.4-1.0 | 29-33 | 1 max |
| Grade | Melting point | Density | Tensilestrength | Elongation | Yieldstrength(0.2%Offset) |
|---|---|---|---|---|---|
| 90/10 | 2260°F | 8.8g/cm3 | 50000 PSi | 30% | 20000 PSi |
| 70/30 | 2260°F | 0.323 lb/in3 at 68°F | 50000 PSi | 30% | 20000 PSi |
| BD | Bright drawn | SRE | Slit rolled edge |
| CF | Cold finished | HRAP | Hot rolled annealed / pickled |
| CG | Centreless ground | HF | Hot finished |
| ST | Smooth turned | PR | Peeled / reeled |
| CD | Cold drawn | P | Polished |
| P&T | Peeled / turned | RT | Rough turned and peeled |
| Metric | US Rods | ASTM/ Canadian | Japanese | ||||
|---|---|---|---|---|---|---|---|
| Rods Size | Diam. (mm) | Rods Size | Diam. (Inch) | Rods Size | Diam. (mm2) | Rods Size | Diam. (mm) |
| 5 | 5 | #2 | 0.250 | 10M | 100 | 6 | 6 |
| 5.5 | 5.5 | #3 | 0.375 | 15M | 200 | 10 | 10 |
| 6 | 6 | #4 | 0.500 | 20M | 300 | 13 | 13 |
| 7 | 7 | #5 | 0.600 | 25M | 500 | 16 | 16 |
| 8 | 8 | #6 | 0.750 | 30M | 700 | 19 | 19 |
| 9 | 9 | #7 | 0.875 | 35M | 1000 | 22 | 22 |
| 10 | 10 | #8 | 1.000 | 45M | 1500 | 25 | 25 |
| 11 | 11 | #9 | 1.125 | 55M | 2500 | 29 | 29 |
| 12 | 12 | #10 | 1.250 | 32 | 32 | ||
| 14 | 14 | #11 | 1.375 | 35 | 35 | ||
| 16 | 16 | #12 | 1.500 | 38 | 38 | ||
| 18 | 18 | #13 | 1.600 | 41 | 41 | ||
| 20 | 20 | #14 | 1.750 | 44 | 44 | ||
| 22 | 22 | #15 | 1.875 | 48 | 48 | ||
| 25 | 25 | #16 | 2.000 | 51 | 51 | ||
| 28 | 28 | #18 | 2.250 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
| Grade | UNS | Werkstoff Nr. |
| 90/10 | C70600 | 2.0872 |
| 70/30 | C71500 | 2.0882 |
Yes, Copper Nickel Rectangular Bars are customizable in terms of size, thickness, length, and alloy composition to meet specific requirements for various applications. Customization ensures optimal performance in marine, chemical, and industrial environments.
Copper Nickel Rectangular Bars find extensive use in applications that demand outstanding resistance to seawater corrosion and biofouling. They are commonly used in marine hardware, shipbuilding components, condenser and heat exchanger tubing plates, offshore oil platforms, and seawater piping systems. Additionally, they play a crucial role in power plants, desalination units, and chemical processing equipment where mechanical strength and corrosion resistance are vital. Their thermal and electrical conductivity, along with ease of fabrication and welding, make them perfect for both structural and functional components in various industrial and commercial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
