Brian Fasteners supplies Aluminium 7050 Bars and Rods, an aerospace-grade high-strength alloy from our Houston factory. 7050 is a heat-treatable aluminum-zinc-magnesium-copper alloy designed with higher strength, corrosion resistance, and toughness—particularly in heavy sections. It has higher stress corrosion cracking resistance than 7075 and is well-suited to aircraft structural parts, aerospace tooling, and defense hardware. Our bars meet AMS and ASTM specifications, shipped in T7451 and T7651 temper conditions. Brian Fasteners delivers the best aluminum products with complete traceability, precise machining, and fast dispatch for high-performance applications requiring stringent demands.
Aluminum 7050 contains ~6.2% zinc, 2.3% magnesium, 2.3% copper, and minor elements like zirconium. It has tensile strength of up to 570 MPa and yield strength ~500 MPa in the T7451 temper condition. The alloy shows good resistance to exfoliation and stress corrosion and is a better choice for thick and heavily loaded structures. It can be heat treated and has good machinability and fatigue life. While not as moldable as lower-strength alloys, 7050 is nevertheless highly dimensionally stable after machining and maintains performance in harsh aerospace environments.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight % | Zn | Cu | Mg | Zr | Fe | Si | Mn | Ti | Cr | Others (total) |
| Minimum | 5.7 | 2.0 | 1.9 | 0.08 | – | – | – | – | – | – |
| Maximum | 6.7 | 2.6 | 2.6 | 0.15 | 0.15 | 0.12 | 0.10 | 0.06 | 0.04 | 0.15 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 515 MPa | 74695 psi |
| Yield strength | 455 MPa | 65992 psi |
| Fatigue strength | 240 MPa | 34809 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 11% | 11% |
| UNS | EN | DIN,WNr | ISO |
| A97050 | EN3982 | 3.4144 | AlZn6CuMgZr |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 7050 bars are ideal for structural applications, particularly in aerospace and military sectors, offering high strength, corrosion resistance, and fatigue resistance, making them suitable for demanding environments and designs.
To maintain Aluminium 7050 bars, regularly clean them with mild soap and water to remove dirt and debris. Avoid harsh chemicals, inspect for corrosion, and store in a dry, cool environment.
Yes, Aluminium 7050 rods are highly recyclable. Aluminium, including alloy 7050, can be recycled multiple times without losing its properties, making it an environmentally friendly choice for sustainable manufacturing and use.
7050 aluminum rods have applications in aircraft fuselage frames, wing spars, landing gear supports, and structural forgings. The high strength-to-weight ratio of the alloy recommends it for military and aerospace vehicles that need performance under dynamic stress. It also finds application in missiles, satellite parts, and high-performance sporting goods. 7050 is utilized where higher strength, corrosion resistance, and resistance to fracture are essential. Brian Fasteners supplies a 7050 aluminum bar that is designed to specification, with aerospace and defense contract certifications and customized services such as precision cutting and custom tempers.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
