Brian Fasteners produces Houston Aluminium 2024 Forgings for high-strength structural applications. A copper-aluminum alloy highly valued in the aerospace industry, 2024 forgings provide exceptional mechanical strength and fatigue resistance. Though slightly less corrosion-resistant, surface finishes maximize durability. Our forgings are AMS and ASTM compliant, providing accuracy shapes and heat treatments that conform to engineering designs. Best suited for aircraft fittings, high-load assemblies, and performance assemblies, Brian Fasteners guarantees high quality and traceability.
Contains ~4.4% Cu, ~1.5% Mg, ~0.6% Mn; the rest Al. Tensile strength ~470 MPa; yield ~325 MPa. Heat-treatable and age-sensitive, possesses superior fatigue resistance and machinability. Has moderate corrosion resistance, which is enhanced through cladding or coatings.
Standards : ASTM B247, B247
Temper : T6 T651 T6511
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.1355 | A92024 | AlCu4Mg1 | 2024 | AlCuMg2 |
Yes, Aluminum 2024 is commonly used in precision forging applications due to its high strength, good fatigue resistance, and excellent machinability, making it suitable for aerospace and high-performance components.
Aluminum 2024 offers high strength, excellent fatigue resistance, good machinability, and superior corrosion resistance, making it ideal for custom forgings in aerospace, military, and high-performance applications.
Applied in aerospace fittings, wing rib forgings, landing gear components, hardware parts, and stress-high structural components. Also applied in precision drive components and military vehicle parts. Brian Fasteners provides 2024 forgings designed to operate in severe fatigue-bearing and high-stress conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
