Brian Fasteners produces and supplies Aluminium 2024 Bars and Rods from Houston, USA, renowned for high strength and fatigue resistance. The copper-aluminum alloy is a mainstay in aerospace and structural designs demanding excellent mechanical performance. Although it possesses moderate corrosion resistance generally improved through cladding, machinability and precision stability cannot be matched. Our 2024 bars are compliant with ASTM B211 and AMS specifications and come in T3, T4, and T351 tempers. Through strict quality control and tailoring, Brian Fasteners provides certified 2024 aluminum rods suitable for aerospace, defense, and high-performance applications.
Contains ~4.4% Cu, 1.5% Mg, 0.6% Mn, balance Al. Tensile strength ~470 MPa and yield ~325 MPa (T4 temper), with very good fatigue resistance. Alloy is heat-treatable, weldable only with special processes, and possesses moderate corrosion resistance. It machines very well and is generally selected for applications where high strength-to-weight ratio and accuracy of dimensions are essential.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2024 | A92024 | 3.1355 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 2024 can be welded, but it is challenging due to its susceptibility to cracking. Specialized techniques like TIG welding with proper filler material and preheating are recommended for best results.
To maintain Aluminium 2024 bars, regularly clean with mild detergent, avoid exposure to harsh chemicals, and apply protective coatings. Store in dry conditions to prevent moisture and corrosion, ensuring longevity.
Yes, Aluminium 2024 can corrode, especially in harsh environments. It has moderate resistance to corrosion, but its susceptibility increases without proper protective coatings, making it prone to pitting and stress corrosion cracking.
Applications: It is utilized in aircraft fuselage frame components, wing skins, and fittings in the aerospace industry. In defense and automotive, it makes high-strength suspension and structural parts. Used in high-load military vehicles and precision machined components. Brian Fasteners provides custom-sized, certified 2024 rods that are designed for fatigue-critical and high-performance uses.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
