Brian Fasteners is pleased to supply Aluminium 2017 Bars and Rods, which are procured and supplied from our Houston, USA office. Being a high-strength aluminum-copper alloy, 2017 is best suited for those applications that demand good machinability and superior mechanical properties. It is commonly used in aerospace, transportation, and structural uses where toughness and wear resistance are critical. Our 2017 bars are produced according to ASTM B211 and AMS specifications to guarantee dimensional precision, close tolerances, and uniform material properties. Brian Fasteners supplies high-quality aluminum products with fast turnaround and complete certification for fabrication, industrial, and engineering markets.
Aluminium 2017 is usually composed of 3.5–4.5% copper, 0.4–1.0% manganese, 0.4–0.8% magnesium, with the remainder being aluminum. It offers a tensile strength of 440–510 MPa and yield strength of ~275 MPa in T4 temper. The alloy has good corrosion resistance but superior fatigue and stress resistance. Having fair weldability and good machinability, 2017 is usually heat treated to improve its mechanical properties. 2017 has a very good strength-to-weight ratio and is ideal for parts that are dynamically loaded.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others Each | Other Total |
| 2017 | Rem | 0.20-0.8 | 0.7 max | 3.5-4.5 | 0.40-1.0 | 0.40-0.8 | 0.10 max | 0.25 max | 0.15 max | 0.05 max | 0.15 max |
| Material | Condition | Tensile Strength (N/mm²) min | Yield Strength | Elongation in 4D % | ||
| ksi | Mpa | ksi | Mpa | |||
| 2017 | 2017-T4 Bar | 55 | 379 | 32 | 221 | 12 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2017 | A92017 | 3.1325 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 2017 can be welded, but it requires careful control due to its high strength and susceptibility to cracking. Specialized welding techniques like TIG or MIG are recommended.
To maintain Aluminium 2017, regularly clean with mild detergent and water, avoid abrasive materials, store in a dry environment, and prevent exposure to corrosive substances to preserve its strength and appearance.
Aluminium 2017 rods are typically sized by diameter and length. Common diameters range from 1/8 inch to several inches, while lengths can vary from a few feet to custom sizes based on needs.
Aluminum 2017 rods and bars are largely employed in aerospace structural components, transportation fittings, rivets, and truck frames. Their excellent mechanical strength finds them suitable in automotive transmission shafts, gears, and drive shafts. The machinability of the alloy renders it suitable in precision-engineered components for machinery and tooling. Though less corrosion-resistant than other alloys of aluminum, 2017 is commonly surface-treated or anodized when employed outdoors. Its thermal conductivity and formability make it ideal for load-bearing, airframes, and custom mechanical components where strength is paramount.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
