George Metals, located in Houston, USA, has built a solid reputation as a manufacturer and supplier that specializes in top-notch Aluminium 1050 forgings. They’re well-known for their dedication to precision engineering and outstanding customer service, serving a variety of industries with dependable and cost-effective solutions. Their Aluminium 1050 forgings are produced using cutting-edge technology, which guarantees consistency, durability, and peak performance. With years of experience in non-heat-treatable aluminum grades, the company upholds strict quality standards and ensures timely deliveries, making them a reliable partner for clients in the aerospace, automotive, electrical, and general manufacturing sectors across the nation.
Aluminium 1050 forgings are made up of 99.5% pure aluminum, giving them impressive ductility and resistance to corrosion. This alloy boasts excellent electrical and thermal conductivity, with a tensile strength ranging from 60 to 95 MPa and an elongation of about 35%. It’s non-heat-treatable but responds well to cold working, which enhances its strength. The material has a Brinell hardness of around 20 HB and shows good reflectivity. While it may not have the mechanical strength of some other alloys, its exceptional workability and chemical stability make it a go-to choice for specialized, lightweight applications.
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
Yes, Aluminum 1050 forgings can be shaped into custom designs through processes like open-die and closed-die forging, allowing for precise, unique shapes tailored to specific applications.
The ideal temperature range for forging Aluminium 1050 forgings is between 350°C to 500°C (660°F to 930°F), ensuring optimal material flow and minimizing the risk of cracking or deformation.
These Aluminium 1050 forgings find their way into industries that demand high thermal and electrical conductivity along with corrosion resistance. They’re perfect for electrical conductors, bus bars, components in heat exchangers, and equipment used in chemical processes. Their excellent formability also makes them a great fit for architectural and decorative uses. In the food and beverage sector, they’re often utilized for utensils and packaging because they’re non-toxic. The lightweight nature of the alloy and its resistance to environmental conditions make it particularly effective in HVAC systems, signage, and structural components related to transportation.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
